Запчасти Komatsu PW180-7K ЦИЛИНДР СТРЕЛЫ(ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XT980

CYLINDER ASSEMBLY,L.H. (FINAL COATING)

G-2

707-01-XT990

CYLINDER ASSEMBLY,R.H. (FINAL COATING)

|1

707-01-0H210

CYLINDER ASSEMBLY

1

707-13-12540

CYLINDER

2

21K-70-71320

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-85410

ROD,PISTON

5

707-76-80230

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12420

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12851

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12140

RING,WEAR (KIT)

20

707-44-12911

RING

21

707-71-70820

PLUNGER

22

07000-15075

O-RING (KIT)

23

707-35-90930

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-71-34650

COLLAR

26

707-35-91220

RING,BACK-UP (KIT)

27

07000-15110

O-RING (KIT)

28

707-86-48080

TUBE,L.H.

|28

707-86-48090

TUBE,R.H.

29

02896-11015

O-RING (KIT)

30

01010-80845

BOLT

31

01643-30823

WASHER

32

01010-80840

BOLT

33

01643-30823

WASHER

34

07000-13025

O-RING (KIT)

35

707-88-25960

BRACKET

36

707-88-21251

BAND

37

07372-21035

BOLT

38

01643-51032

WASHER

39

07283-32236

CLIP

40

01597-01009

NUT

41

01643-31032

WASHER

|K

707-99-46330

SERVICE KIT
