Запчасти Komatsu PW180-7K ЗАДН. МОСТ (/7) (.M ШИР.) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

20J-22-11111

2.50M REAR AXLE INCLUDES TRANSMISSION ASSEMBLY

|1

20J-14-11110

TRANSMISSION ASSEMBLY

1

20J-22-11300

HOUSING

2

20K-14-31140

SCREW

3

20K-14-31530

WASHER

4

20K-14-31460

SLEEVE

5

20G-22-31390

FITTING

6

20K-14-31550

BEARING,ROLLER

7

20K-14-31490

BUSHING

8

20K-14-31520

ROD,CONTROL

9

20K-14-31570

BEARING,ROLLER

10

20G-22-31280

WASHER

11

20K-14-31580

O-RING

12

20K-14-31560

CIRCLIP

13

20G-22-31440

GEAR,SPUR

14

20K-14-31540

WASHER

15

20K-14-31480

GEAR,PINION

16

20K-14-31290

SHIM

17

20K-14-31040

GEAR,CROWN

18

20K-14-31320

O-RING

19

20K-14-31060

GEAR

20

20K-14-31130

CIRCLIP

21

20K-14-31090

CIRCLIP

22

20K-14-31310

SHIM

23

20K-14-31160

WASHER

24

20K-14-32330

PLUG

25

20K-14-31260

SHIM

26

20K-14-31270

SHIM

27

20K-14-32320

PLUG

28

20K-14-31240

BEARING,BALL

29

20K-14-31250

BEARING,BALL

30

20K-14-31070

PRESSURE PLATE

31

20K-14-31080

PRESSURE RING

32

20K-14-31030

RING

33

20J-22-11340

SHIM

34

20J-22-11850

FLANGE

35

20K-14-31340

O-RING

36

20K-14-31370

O-RING

37

20J-22-11360

FLANGE

38

20K-14-31380

O-RING

39

20K-14-31280

CIRCLIP

40

20K-14-31050

SLEEVE

41

20K-14-31360

SCREW

42

20K-14-31170

WASHER

43

20G-22-31540

WASHER

44

20G-22-31550

WASHER

45

20G-22-31710

PROTECTION

46

20G-22-31720

SCREW

47

20J-22-11410

PLUG

|48

20G-22-31410

PLANETARY CARRIER ASSEMBLY

48

20J-22-11430

PLANETARY CARRIER

49

20K-14-31420

SPUR GEAR ASSEMBLY

50

20K-14-31430

PIN

51

20K-14-31440

WASHER,AXIAL
