Запчасти Komatsu PW180-7E0 ОХЛАЖД-Е (ОХЛАДИТЕЛЬ - ВНУТР. ЧАСТИ) C СИСТЕМА ОХЛАЖДЕНИЯ

|$1

20J-03-12101

COOLER ASSEMBLY

1

203-03-41410

HOSE

2

205-03-62660

PLUG

3

206-03-43340

CLIP

4

208-979-7520

CONDENSER ASSEMBLY

5

01010-81025

BOLT

6

01024-80616

BOLT

7

01024-81020

BOLT

8

01024-81025

BOLT

9

01024-81225

BOLT

10

01024-81245

BOLT

11

01434-10616

BOLT, WING

12

01597-01009

NUT

13

01643-30623

WASHER

14

01643-31032

WASHER

15

07283-34354

CLIP

16

07283-54353

SEAT

17

20J-03-12110

RADIATOR ASSEMBLY

18

20J-03-12490

WASHER

19

20J-03-12510

COLLAR

20

20J-03-12130

FRAME, LHS

21

20J-03-12140

FRAME, RHS

22

20J-03-12150

FRAME, BASE

23

20J-03-12160

FRAME, TOP

24

20J-03-12170

PLATE

25

20J-03-12180

CUSHION

26

20J-03-12380

SHEET

27

20J-03-12390

SHEET

28

20J-03-12220

SHEET

29

20J-03-12190

SHEET

30

20J-03-12210

SHEET

31

20J-03-11310

SHEET

32

20J-03-12240

OIL COOLER ASSEMBLY

33

20J-03-12340

NET, (WELDED)

34

20J-03-12350

NET, (WELDED)

35

20J-03-12370

COVER

36

20J-03-12360

PLATE

37

20J-03-12410

PIPE, INLET

38

20J-03-12421

PIPE, OUTLET

39

20J-03-11530

BRACKET

40

20J-03-12451

BRACKET

41

20J-03-12460

AFTER COOLER

42

20J-03-12520

HOSE

43

20J-03-12430

BRACKET

44

20Y-03-11330

CLIP

45

20Y-03-22110

CAP

46

20J-03-12280

SHEET

47

07000-13045

O-RING
