Запчасти Komatsu PW180-7E0 КЛАПАН ПЕРЕГРУЗКИ LHS (ДЛЯ ЦИЛИНДРА СТРЕЛЫ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

702-21-08350

PILOT VALVE

1

BODY, VALVE

2

SPOOL

3

702-21-38750

CASE

4

702-21-38420

RETAINER, 2.0MM

|$6

702-21-38550

RETAINER, 1.7MM

|$7

702-21-38560

RETAINER, 2.3MM

|$8

702-21-38610

RETAINER, 1.8MM

|$9

702-21-38620

RETAINER, 1.9MM

|$10

702-21-38630

RETAINER, 2.1MM

|$11

702-21-38640

RETAINER, 2.2MM

5

702-21-38430

FLANGE

6

702-21-38440

SPRING

7

702-21-38650

SPRING

8

702-21-38460

O-RING

9

702-21-38470

O-RING

10

702-21-38480

PLUG

11

01252-60860

BOLT

12

01252-60865

BOLT

13

01252-60620

BOLT

14

01641-20608

WASHER

15

07000-12021

O-RING

16

709-74-92810

VALVE

17

709-75-92220

SPRING

18

700-93-11320

O-RING

19

700-93-11330

RING, BACK-UP

20

723-40-91500

VALVE ASSEMBLY, RELIEF

21

700-80-64220

RING

22

700-22-11410

O-RING

23

709-25-11390

O-RING
