Запчасти Komatsu PW180-7E0 ОСНОВН. КЛАПАН (8-СЕКЦИОНН.) (TWO-ЧАСТИ СТРЕЛА) (7/9) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

723-58-17700

MAIN VALVE (8-SPOOL/1 ATTACHMENT)

|$3

723-50-51500

VALVE ASSEMBLY

1

BLOCK

2

SPOOL

3

723-50-51230

SPRING

4

723-50-51140

PLUG

5

07002-11623

O-RING

6

723-50-51150

FLANGE

7

07000-12011

O-RING

8

07000-11007

O-RING

9

01252-60620

BOLT

10

700-84-11730

BALL

11

723-50-51160

PLUG

12

07000-11003

O-RING

13

07002-10823

O-RING

14

SCREW

15

07000-11008

O-RING

|$19

723-50-54200

VALVE ASSEMBLY

16

723-50-54110

BLOCK

17

723-50-54120

VALVE

18

723-56-31620

SPRING

19

723-56-31630

PLUG

20

07002-11623

O-RING

21

723-11-18190

PLUG

22

07002-11023

O-RING

23

07000-11009

O-RING

24

708-2L-25490

O-RING
