Запчасти Komatsu PW180-7E0 ОСНОВН. КЛАПАН (8-СЕКЦИОНН.) (TWO-ЧАСТИ СТРЕЛА) (/9) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

723-58-17700

MAIN VALVE (8-SPOOL/1 ATTACHMENT)

|$3

BLOCK GROUP

1

BLOCK

2

144-14-54610

O-RING

3

723-56-31730

O-RING

4

702-75-11520

O-RING

5

07000-11008

O-RING

6

SLEEVE

7

PISTON

8

PISTON

9

723-36-15240

SPRING

10

723-36-15250

CASE

11

723-56-32840

CASE

12

07000-13042

O-RING

13

723-56-32860

SEAL

14

01252-60820

BOLT

15

723-56-31630

PLUG

16

07002-11623

O-RING

|$20

COVER GROUP

17

COVER

18

723-50-11311

PLUG

19

07000-11004

O-RING

20

07001-01004

RING

21

07002-11423

O-RING

22

723-26-15190

PLUG

23

07000-11007

O-RING

24

07001-01007

RING, BACK-UP

25

07000-11009

O-RING

26

07001-01009

RING

27

708-8E-16160

PLUG

28

07002-11023

O-RING

29

723-56-33840

UNION

30A

07000-13024

O-RING

30B

02896-11018

O-RING

31

723-50-11180

STUD

32

01643-31232

WASHER

33

01580-11210

NUT

34

01252-60850

BOLT
