Запчасти Komatsu PW180-7E0 СТРЕЛА ADJUST ЦИЛИНДР Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XS010

ADJUST CYLINDER ASSEMBLY

|$2

707-01-0H230

CYLINDER ASSEMBLY

1

707-13-16990

CYLINDER

2

707-76-90440

BUSHING

3

07145-00090

SEAL, DUST (KIT)

4

721-58-10040

ROD, PISTON

5

707-76-90130

BUSHING

6

07145-00090

SEAL, DUST (KIT)

7

707-27-16940

HEAD, CYLINDER

9

07179-13114

RING, SNAP

8

176-63-56170

SEAL, DUST (KIT)

10

707-52-90780

BUSHING

11

707-51-10030

PACKING, ROD (KIT)

12

707-51-10640

RING, BUFFER (KIT)

13

07000-15150

O-RING (KIT)

14

707-35-91640

RING, BACK-UP (KIT)

15

01010-82085

BOLT

16

707-88-75310

WASHER

17

707-36-16580

PISTON

18

707-44-16180

RING, PISTON (KIT)

19

707-39-16120

RING, WEAR (KIT)

20

707-44-16910

RING

21

01310-01216

SCREW

22

07001-05100

RING, BACK-UP (KIT)

23

07000-15100

O-RING (KIT)

24

707-86-48110

TUBE

25

02896-11015

O-RING (KIT)

26

07000-13030

O-RING (KIT)

27

07372-21060

BOLT

28

01643-51032

WASHER

29

07372-21045

BOLT

30

01643-51032

WASHER

31

707-88-25980

BRACKET

32

707-88-21660

BAND

33

07372-21035

BOLT

34

01643-51032

WASHER

35

07283-32236

CLIP

36

01597-01009

NUT

37

01643-31032

WASHER

KIT

707-99-66270

SERVICE KIT
