Запчасти Komatsu PW180-7E0 ЦИЛИНДР РУКОЯТИ(С КЛАПАН БЕЗОПАСНОСТИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XS030

CYLINDER ASSEMBLY

1

707-88-21630

BAND

2

707-88-22930

BRACKET

3

707-88-22970

BRACKET

4

07372-21035

BOLT

5

01643-51032

WASHER

6

707-88-21620

BAND

|$8

707-01-0H240

CYLINDER ASSEMBLY

7

07145-00080

SEAL (KIT)

8

707-76-80230

BUSHING

9

01010-81670

BOLT

10

01643-51645

WASHER

11

07179-13099

RING

12

707-56-85510

SEAL (KIT)

13

707-27-12921

HEAD

14

707-51-85030

PACKING (KIT)

15

707-51-85640

RING (KIT)

16

707-35-91220

RING (KIT)

17

07000-15110

O-RING (KIT)

18

707-52-90610

BUSHING

19

707-35-91220

RING (KIT)

20

07000-15110

O-RING (KIT)

21

707-71-34640

COLLAR

22

707-13-12340

CYLINDER

23

707-58-85310

ROD

24

707-71-70820

PLUNGER

25

707-44-12911

RING

26

707-39-12140

RING (KIT)

27

707-44-12180

RING (KIT)

28

707-36-12851

PISTON

29

707-71-91270

CAP

30

04260-00635

BALL

31

707-71-80230

PLUNGER

32

707-83-13010

VALVE

33

07750-01628

SPRING

34

07002-12034

O-RING (KIT)

35

707-87-14070

PLUG

36

707-35-90930

RING (KIT)

37

07000-15075

O-RING

38

01310-01216

SCREW

KIT

707-99-46320

SERVICE KIT
