Запчасти Komatsu PW180-7E0 ЦИЛИНДР РУКОЯТИ(КЛАПАН БЕЗОПАСНОСТИ LESS) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XS020

ARM CYLINDER ASSEMBLY

1

01643-51032

WASHER

2

07372-21045

BOLT

3

07372-21060

BOLT

4

707-86-66770

TUBE

5

02896-61018

O-RING (KIT)

6

707-88-22970

BRACKET

7

707-88-21630

BAND

8

07283-32738

CLIP

9

01597-01009

NUT

10

01643-31032

WASHER

11

07372-21035

BOLT

12

01643-51032

WASHER

13

707-88-22930

BRACKET

14

707-88-21620

BAND

15

07000-13030

O-RING (KIT)

|$17

707-01-0H240

CYLINDER ASSEMBLY

16

01010-81670

BOLT

17

01643-51645

WASHER

18

07145-00080

SEAL (KIT)

19

707-76-80230

BUSHING

20

07179-13099

RING

21

707-56-85510

SEAL (KIT)

22

707-27-12921

HEAD

23

707-51-85030

PACKING (KIT)

24

707-51-85640

RING (KIT)

25

707-35-91220

RING (KIT)

26

07000-15110

O-RING (KIT)

27

707-52-90610

BUSHING

28

707-35-91220

RING (KIT)

29

07000-15110

O-RING (KIT)

30

707-71-34640

COLLAR

31

707-13-12340

CYLINDER

32

707-58-85310

ROD

33

707-71-70820

PLUNGER

34

707-35-90930

RING (KIT)

35

07000-15075

O-RING (KIT)

36

707-44-12911

RING

37

707-39-12140

RING (KIT)

38

707-44-12180

RING (KIT)

39

707-36-12851

PISTON

40

707-71-91270

CAP

41

04260-00635

BALL

42

707-71-80230

PLUNGER

43

707-83-13010

VALVE

44

07750-01628

SPRING

45

07002-12034

O-RING (KIT)

46

707-87-14070

PLUG

47

01310-01216

SCREW

KIT

707-99-46320

SERVICE KIT
