Запчасти Komatsu PW180-7E0 CENTRAL СМАЗКА (.9M РУКОЯТЬ) W РАЗНОЕ

Схема запчастей Komatsu PW180-7E0 - CENTRAL СМАЗКА (.9M РУКОЯТЬ) W РАЗНОЕ
31
C
C
32
D
D
33
F
24
F
E
E
B
B
A
34
A
25
12
26
13
24
26
11
23
22
24
37
27
38
21
28
16
35
36
10
9
15
8
14
15
19
14
39
29
30
6
7
17
20
18
1
2
3
4
5
40

Артикул

Название

Примечание

Количество

1

42W-09-H3220

UNION

2

42R-09-H1760

UNION

3

42W-09-H2940

CAP

4

42W-09-H2900

UNION

5

42W-09-H3060

UNION

6

20J-S95-H160

LUBRICATION TUBE

7

20J-S95-H170

LUBRICATION TUBE

8

20J-S95-H460

BRACKET

9

01010-81220

BOLT

10

01643-31232

WASHER

11

20J-S95-H141

BRACKET

12

01016-51030

BOLT

13

01643-31032

WASHER

14

42W-09-H2910

UNION

15

42W-09-H2940

CAP

16

42W-09-H3620

PROGRESSIVE FEEDER

17

419-09-H2780

UNION

18

42W-09-H2940

CAP

19

423-00-H1690

STRAIGHT COUPLING

20

20J-S95-H121

BRACKET

21

20J-S95-H350

LUBRICATION TUBE

22

20J-S95-H360

LUBRICATION TUBE

23

20J-S95-H110

BRACKET

24

423-00-H1690

STRAIGHT COUPLING

25

419-09-H2780

UNION

26

42W-09-H2940

CAP

27

20J-S95-H200

LUBRICATION TUBE

28

423-00-H1860

ELBOW

29

419-09-H2780

UNION

30

42W-09-H2940

CAP

31

205-70-66580

PLATE

32

01643-31232

WASHER

33

01010-81230

BOLT

34

20G-S95-H391

HOSE

35

01643-31032

WASHER

36

01016-51030

BOLT

37

01643-51032

WASHER

38

01010-81020

BOLT

39

08034-00519

BAND

40

418-09-H0390

CONNECTOR

Выбрано товаров: 40
