Запчасти Komatsu PW180-7E0 CENTRAL СМАЗКА (ФИДЕР ONE-ЧАСТИ-СТРЕЛА) W РАЗНОЕ

|$1

20J-S95-H250

PROGRESSIVE FEEDER

1

419-09-H2850

PLASTIC TUBE, 1.08M (MARK 11)

2

419-09-H3150

COVER, 1.00M SPIRAL

3

419-09-H2850

PLASTIC TUBE, 2.30M (MARK 14)

4

419-09-H3150

COVER, 2.23M SPIRAL

5

419-09-H2850

PLASTIC TUBE, 1.08M (MARK 12)

6

419-09-H3150

COVER, 1.00M SPIRAL

7

42W-09H3970

HOSE (MARK 4)

8

42W-09H3970

HOSE (MARK 3)

9

419-09-H2850

PLASTIC TUBE, 3.60M (MARK 5)

10

42W-09-H4110

COVER SPIRAL

11

42W-09-H2880

UNION

12

42W-09-H3840

HOSE (MARK A)

13

419-09-H2850

PLASTIC TUBE, 3.10M (MARK 1)

14

419-09-H2850

PLASTIC TUBE, 3.60M (MARK 6)

15

421-09-H3870

NIPPLE

16

42W-09-H3350

CAP

17

42W-09-H3890

PLATE

18

01010-80640

BOLT

19

42W-09-H2940

CAP

20

20G-09-H1220

PROGRESSIVE FEEDER, (WITH VALVES)

21

42W-09-H4650

VALVE

22

01252-61035

BOLT

23

01643-31032

WASHER

24

419-09-H2950

CONNECTOR

25

419-09-H2970

ELBOW

26

419-09-H2780

CONNECTOR

27

419-09-H2980

ELBOW

28

42W-09-H3340

BLOCK

29

01252-60625

SCREW

30

42W-09-H2940

CAP

31

421-09-H3100

BAND

32

421-09-H3110

BAND

33

421-09-H3870

NIPPLE

34

42W-09-H3350

CAP

35

42W-09-H2880

UNION
