Запчасти Komatsu PW180-7E0 ЗАДН. МОСТ (/7) (.M ШИР.) КОЛЕСА ВТУЛКА И PLANETARY НЕСУЩИЙ ЭЛЕМЕНТ НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$1

20J-22-11111

AXLE ASSEMBLY, REAR

1

20K-22-31120

HUB

|$34

20K-22-31850

WHEEL STUD

2

20K-22-31130

GEAR

3

20K-22-31140

SLEEVE

|$6

20J-22-11150

PLANETARY CARRIER ASSEMBLY

4

20J-22-11160

PLANETARY CARRIER

5

20K-22-31170

GEAR, SPUR

6

20K-22-31270

PLUG

7

20K-22-31180

WASHER

8

20K-22-31190

BEARING, ROLLER

9

20K-14-32330

PLUG

10

20G-23-31370

CLIP

11

20K-22-31820

SHAFT

12

20K-22-31230

WHEEL

13

20K-22-31240

CIRCLIP

14

20K-22-31250

WASHER

15

20K-22-31260

BUSHING

16

20K-22-31270

PLUG

17

20K-22-31280

PLUG

18

20K-22-31440

O-RING

19

20K-22-31310

GASKET

20

20G-23-H0P20

VALVE

20

20G-23-31670

VALVE

21

20G-23-31510

FITTING

22

20K-22-31350

PLUG

23

20K-22-31360

PLUG

24

20K-22-31370

BEARING

25

20K-22-31380

SCREW

26

20K-22-31390

SCREW

27

20J-22-11200

SHIM

28

20K-22-31410

SHIM, 0.3MM

29

20K-22-31420

SHIM, 0.5MM

30

20K-22-31430

CIRCLIP
