Запчасти Komatsu PW180-7E0 OPERATORS КАБИНА (ПЕРЕДН. ОКНА, ВЕРХН.) K OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

20J-54-12010

OPERATORS CAB ASSEMBLY

1

20J-54-10020

WINDOW ASSEMBLY

2

20J-54-11510

FRAME

3

20Y-54-51522

GLASS

4

20Y-54-51531

SEAL

5

20Y-54-51551

SEAL

6

22B-54-15411

LOCK ASSEMBLY

7

22B-54-15440

CASE

8

22B-54-15470

KNOB

9

22B-54-15421

LOCK ASSEMBLY

10

22B-54-15450

CASE

11

22B-54-15480

KNOB

12

01435-40812

BOLT

13

20Y-54-52621

ROLLER

14

20Y-54-52681

ROLLER

15

208-53-12690

PIN

16

20Y-54-14590

HANDLE

17

01023-10616

SCREW

18

208-53-12630

BRACKET

19

208-53-12830

BRACKET

20

01245-00816

SCREW

21

20Y-54-51670

STOPPER

22

20Y-54-51680

STOPPER

23

01252-80616

BOLT

24

01643-70623

WASHER

25

208-53-11560

BLOCK

26

01245-00816

SCREW

27

01643-70823

WASHER

28

20Y-54-51633

BLOCK

29

20Y-54-52192

BLOCK

30

01252-80616

BOLT

31

01641-50608

WASHER

32

22B-54-15621

STOPPER

33

22B-54-15432

STRIKER

34

01435-40616

BOLT

35

21J-06-12440

SWITCH

36

01583-11811

NUT

37

20Y-54-51880

BRACKET

38

01435-40616

BOLT

39

20Y-54-11611

STOPPER

40

01580-11008

NUT

41

20Y-54-52491

PLATE

42

01435-40616

BOLT

43

20Y-54-51621

STRIKER

44

208-53-11540

SEAL

45

20Y-54-51591

SPRING ASSEMBLY

46

01435-00616

BOLT

47

20Y-54-51640

HOLDER

48

20Y-54-51420

SEAL

49

208-53-11470

BRACKET

50

01435-40616

BOLT
