Запчасти Komatsu PW180-10 СМАЗКА РУКОЯТЬ, MM, С АВТОМАТИЧ. СМАЗКОЙ, РУКОЯТЬ СМАЗКА РУКОЯТЬ, MM, С АВТОМАТИЧ. СМАЗКОЙ

1

42W-09-H3020

Feeder, Arm

2

42W-09-H3760

Elbow

3

42W-09-H4650

Valve

4

42W-09-H2940

Cap

5

421-09-H3870

Nipple

6

42W-09-H3350

Cap

7

42W-09-H3770

Plate

8

01010-80640

Bolt

9

423-00-H2210

Washer

10

42W-09-H0P03

Hose, 5m

10

42W-09-H0P04

Hose, 10m

10

42W-09-H0P05

Hose, 15m

11

419-S95-HP14

Bushing

12

419-S95-HP13

Tube

13

42W-09-H0P00

Hose, 5m

13

42W-09-H0P01

Hose, 10m

13

42W-09-H0P02

Hose, 15m

14

423-00-H1920

Bushing

15

42T-09-H3810

Tube

16

423-00-H0P12

Tube, 90 Degrees

17

42T-09-H4090

Tube, 45 Degrees

18

425-09-H0260

Tube

19

419-09-H2950

Connector

20

419-09-H2780

Connector

21

419-09-H2970

Elbow

22

42W-09-H2940

Cap

23

42W-09-H2910

Union

24

42R-09-H1760

Coupling

25

42W-09-H3220

Union

26

42W-09-H3060

Union

27

42W-09-H2900

Union

28

423-00-H1860

Elbow

29

423-00-H1690

Straight Coupling

30

20J-S95-H110

Bracket

31

20J-S95-H200

Lubrication Tube

32

20J-S95-H340

Lubrication Tube

33

20J-S95-H330

Lubrication Tube

34

20J-S95-H121

Bracket

35

01016-51030

Bolt

36

01643-31032

Washer

37

20J-S95-H540

Bracket

38

20J-S95-4170

Lubrication Tube

39

20J-S95-H321

Lubrication Tube

40

20J-S95-4190

Bracket

41

01010-81220

Bolt

42

01643-31232

Washer

43

04434-52310

Clip

44

08034-00519

Band

45

20J-S95-H560

Lubrication Tube

46

42W-09-H4800

Union

47

418-09-H0390

Connector

48

20J-70-H1230

Bracket

48

20J-70-H1230

Bracket
