Запчасти Komatsu PW180-10 СМАЗКА РУКОЯТЬ, 9MM, С CENTRAL СМАЗКА СИСТЕМА, РУКОЯТЬ СМАЗКА РУКОЯТЬ, 9MM, С CENTRAL СМАЗКА СИСТЕМА

Схема запчастей Komatsu PW180-10 - СМАЗКА РУКОЯТЬ, 9MM, С CENTRAL СМАЗКА СИСТЕМА, РУКОЯТЬ СМАЗКА РУКОЯТЬ, 9MM, С CENTRAL СМАЗКА СИСТЕМА
a
a
21
A
B
A
B
22
17
14
12
11
13
10
20
22
29
14
32
30
29
28
17
33
31
44
29
31
36
44
35
20
22
34
15
14
13
10
16
44
14
11
13
14
13
43
16
4
12
3
22
2
45
19
6
1
37
5
3
36
4
5
8
35
6
9
15
40
42
7
14
41
13
18
39
14
14
13
18
23
23
26
14
14
27
38
18
18
23
39
24
38
25
46

Артикул

Название

Примечание

Количество

1

42W-09-H3620

Feeder, Arm

2

42W-09-H3760

Elbow

3

42W-09-H4650

Valve

4

42W-09-H2940

Cap

5

421-09-H3870

Nipple

6

42W-09-H3350

Cap

7

42W-09-H3770

Plate

8

01010-80645

Bolt

9

01643-30623

Washer

10

42W-09-H0P03

Hose, 5m

10

42W-09-H0P04

Hose, 10m

10

42W-09-H0P05

Hose, 15m

11

419-S95-HP14

Bushing

12

419-S95-HP13

Tube

13

42W-09-H0P00

Hose, 5m

13

42W-09-H0P01

Hose, 10m

13

42W-09-H0P02

Hose, 15m

14

423-00-H1920

Bushing

15

42T-09-H3810

Tube

16

423-00-H0P12

Tube, 90 Degrees

17

42T-09-H4090

Tube, 45 Degrees

18

425-09-H0260

Tube

19

419-09-H2950

Connector

20

419-09-H2780

Connector

21

419-09-H2970

Elbow

22

42W-09-H2940

Cap

23

42W-09-H2910

Union

24

42R-09-H1760

Coupling

25

42W-09-H3220

Union

26

42W-09-H3060

Union

27

42W-09-H2900

Union

28

423-00-H1860

Elbow

29

423-00-H1690

Straight Coupling

30

20J-S95-H110

Bracket

31

20J-S95-H200

Lubrication Tube

32

20J-S95-H360

Lubrication Tube

33

20J-S95-H350

Lubrication Tube

34

20J-S95-H121

Bracket

35

01016-51030

Bolt

36

01643-31032

Washer

37

20J-S95-H141

Bracket

38

20J-S95-H160

Lubrication Tube

39

20J-S95-H171

Lubrication Tube

40

20J-S95-H460

Bracket

41

01010-81220

Bolt

42

01643-31232

Washer

43

04434-52310

Clip

44

08034-00519

Band

45

418-09-H0390

Connector

46

20J-70-H1180

Bracket

46

20J-70-H1180

Bracket

46

20J-70-H1180

Bracket

Выбрано товаров: 52
