Запчасти Komatsu PW180-10 СМАЗКА TWO-ЧАСТИ СТРЕЛА, С CENTRAL СМАЗКА СИСТЕМА СМАЗКА TWO-ЧАСТИ СТРЕЛА, С CENTRAL СМАЗКА СИСТЕМА

1

20J-S95-5640

Feeder, Boom

2

42W-09-H4650

Valve

3

42W-09-H2940

Cap

4

07005-01412

Seal Washer

5

42W-09-H6790

Straight Connector

6

42W-09-H3330

Elbow

7

421-09-H3870

Nipple

8

42W-09-H3350

Cap

9

42W-09-H0P00

Hose, 5m

9

42W-09-H0P01

Hose, 10m

9

42W-09-H0P02

Hose, 15m

10

423-00-H1920

Bushing

11

42T-09-H4090

Tube, 45 Degrees

12

421-00-H0P13

Tube

13

419-09-H2970

Elbow

14

419-09-H2950

Connector

15

42W-09-H0P06

Hose, 5m

15

42W-09-H0P07

Hose, 10m

15

42W-09-H0P08

Hose, 15m

16

01010-80645

Bolt

17

01643-30623

Washer

18

42W-09-H3340

Block

19

01010-80630

Bolt

20

01643-30623

Washer

21

42W-09-H2880

Union

22

20J-S95-5590

Plate

23

20J-S95-5180

Bracket

24

04435-51510

Clip

25

01010-81020

Bolt

26

01643-31032

Washer

27

01010-81016

Bolt

28

01643-31032

Washer

29

04435-50810

Clip

30

04434-51508

Clip

31

04434-50812

Clip

32

421-00-H0260

Band
