Запчасти Komatsu PW180-10 СМАЗКА ONE-ЧАСТИ СТРЕЛА, С CENTRAL СМАЗКА СИСТЕМА СМАЗКА ONE-ЧАСТИ СТРЕЛА, С CENTRAL СМАЗКА СИСТЕМА

1

20J-S95-5290

Feeder, Boom

2

42W-09-H4650

Valve

3

42W-09-H2940

Cap

4

42W-09-H6790

Straight Connector

5

42W-09-H3330

Elbow

6

421-09-H3870

Nipple

7

42W-09-H3350

Cap

8

42W-09-H0P00

Hose, 5m

8

42W-09-H0P01

Hose, 10m

8

42W-09-H0P02

Hose, 15m

9

423-00-H1920

Bushing

10

42T-09-H4090

Tube, 45 Degrees

11

421-00-H0P13

Tube

12

42W-09-H2940

Cap

13

419-09-H2970

Elbow

14

419-09-H2950

Connector

15

42W-09-H0P06

Hose, 5m

15

42W-09-H0P07

Hose, 10m

15

42W-09-H0P08

Hose, 15m

16

01010-80645

Bolt

17

01643-30623

Washer

18

42W-09-H3340

Block

19

01010-80630

Bolt

20

01643-30623

Washer

21

42W-09-H2880

Union

22

20J-S95-5990

Bracket

23

01010-81025

Bolt

24

01643-31032

Washer

25

20J-S95-5180

Bracket

26

01010-81020

Bolt

27

01643-31032

Washer

28

04435-51810

Clip

29

04435-51510

Clip

30

01572-21012

Seat

31

04435-50810

Clip

32

04434-51610

Clip

33

01010-81016

Bolt

34

01643-31032

Washer

35

421-00-H0260

Band
