Запчасти Komatsu PW180-10 ЦИЛИНДР КОВША, ВНУТР. ЧАСТИ ЦИЛИНДР КОВША

|$1

707-01-XS041

Cylinder Assembly (Final Coating)

|$2

707-01-0H261

Cylinder Assembly

1

707-13-10531

Cylinder

2

707-76-70230

Bushing

3

07145-00070

Seal, Dust, (Kit : K07)

4

707-58-70C20

Rod, Piston

5

707-76-70370

Bushing

6

20Y-70-23220

Seal, Dust, (Kit : K07)

7

707-27-10750

Head, Cylinder

8

07179-12084

Ring, Snap

9

707-56-70740

Seal, Dust, (Kit : K07)

10

707-52-90471

Bushing

11

707-51-70030

Packing, Rod, (Kit : K07)

12

07000-15095

O-Ring, (Kit : K07)

13

707-35-91060

Ring, Back-Up, (Kit : K07)

14

707-51-70650

Ring, Buffer, (Kit : K07)

15

707-75-70110

Ring, Snap

16

01010-81465

Bolt

17

705-17-04980

Washer

18

707-36-10760

Piston

19

707-44-10250

Ring, Piston, (Kit : K07)

20

707-39-10550

Ring, Wear, (Kit : K07)

21

707-44-10911

Ring

22

707-35-90730

Ring, Back-Up, (Kit : K07)

23

707-34-60030

O-Ring, (Kit : K07)

24

01310-01216

Screw

25

07020-00000

Fitting, Grease

26

707-86-48120

Tube

27

01010-80850

Bolt

28

01643-30823

Washer

29

07000-13025

O-Ring, (Kit : K07)

30

707-88-22940

Bracket

31

707-88-21650

Band

32

07372-21035

Bolt

33

01643-51032

Washer

34

07283-32236

Clip

35

01597-01009

Nut

36

01643-31032

Washer

37

707-88-33030

Head

38

07371-30640

Flange, Split

39

07372-21035

Bolt

40

01643-51032

Washer
