Запчасти Komatsu PW180-10 СИСТЕМА ОХЛАЖДЕНИЯ, ОХЛАДИТЕЛЬ СИСТЕМА ОХЛАЖДЕНИЯ

1

01010-81030

Bolt

2

01010-81045

Bolt

3

01010-80616

Bolt

4

01643-30623

Washer

5

01016-50825

Bolt

6

01643-30823

Washer

7

01010-81020

Bolt

8

01643-31032

Washer

9

01016-51030

Bolt

10

01643-31032

Washer

11

01010-81040

Bolt

12

01643-31032

Washer

13

01010-81230

Bolt

14

01643-31232

Washer

15

07002-12034

O-Ring

16

14X-03-51621

Cushion

17

14X-03-51640

Spacer

18

14X-03-51770

Washer

19

203-03-41410

Hose

20

203-54-56970

Washer

21

205-03-62660

Plug

22

206-03-21310

Sheet

23

206-03-31480

Sheet

24

206-03-35141

After Cooler Assembly

25

206-03-43340

Clip

26

208-03-41580

Collar

27

208-03-41590

Cushion

28

208-03-71161

Fuel Cooler

29

208-979-7520

Condenser Assembly

|$30

20J-03-51140

Radiator Assembly

31

20J-03-51230

Sheet

32

20J-03-51240

Sheet

33

20Y-03-42160

Sheet

34

20J-03-51220

Bracket

35

20J-03-51281

Shroud

36

20J-03-51291

Cover

37

20J-03-51311

Seal

38

20J-03-51320

Sheet

39

20J-03-51340

Sheet

40

20J-03-51350

Sheet

41

20J-03-51360

Sheet

42

20J-03-51370

Bracket

43

20J-03-51380

Bracket

44

198-06-62820

Hinge

45

20J-03-51460

Stay

46

20J-03-51470

Bracket

47

20J-03-51480

Bracket

48

20J-03-51490

Hose

49

20J-03-51650

Sheet

50

20J-03-51660

Sheet

51

20J-03-51161

Frame

52

20J-03-51331

Sheet

|$54

20J-03-51391

Cover

54

20J-03-51421

Sheet

55

20J-03-51750

Sheet

56

20J-03-51760

Sheet

|$59

20J-03-51431

Cover

58

20J-03-51450

Sheet

59

20J-03-51770

Sheet

60

20Y-03-11330

Clip

61

20Y-03-22110

Cap

62

20Y-03-41580

Cushion

63

20Y-03-41590

Cushion

64

2A5-03-11330

Cover

65

2A5-03-11490

Sheet

66

2A5-03-11521

Sheet

67

2A5-03-11571

Sheet

68

2A5-03-11970

Stay

69

2A5-03-12130

Elbow

70

6110-23-6490

Spacer

71

20J-03-51151

Oil Cooler Assembly
