Запчасти Komatsu PW180-10 КАБИНА, ПОЛ, ПЕДАЛЬ ХОДА И ТРУБЫ КАБИНА

1

702-16-06040

Valve

2

01010-80840

Bolt

3

01643-30823

Washer

4

01010-80820

Bolt

5

01643-30823

Washer

6

195-01-14540

Collar

7

20Y-62-43470

Nipple

8

02896-11008

O-Ring

9

07000-12011

O-Ring

10

11Y-62-12140

Nipple

11

02896-11008

O-Ring

12

07000-12011

O-Ring

13

22B-914-2360

Tee

14

02896-11008

O-Ring

|$15

20G-62-41160

Hose Assembly

15

02760-00215

Hose

15

20Y-62-22820

Band, Blue

15

20Y-62-22840

Band, Black

16

02764-00213

Hose

16

20Y-62-22820

Band, Blue

16

20Y-62-22850

Band, Green

17

02764-00217

Hose

17

20Y-62-22790

Band, Red

17

20Y-62-22850

Band, Green

18

02761-00218

Hose

18

20Y-62-22850

Band, Green

19

08034-00519

Band

20

20J-43-12250

Seat

21

01583-11408

Nut

22

20E-43-41160

Pedal

23

01010-81025

Bolt

24

01643-31032

Washer

25

14X-43-12110

Pedal Cap

26

01016-51070

Bolt

27

01580-11008

Nut

28

20G-62-41870

Hose

29

20Y-62-22840

Band, Black

30

20Y-62-22820

Band, Blue

31

02761-00203

Hose

32

02781-0021D

Union

33

02896-11008

O-Ring

34

07002-11423

O-Ring

35

21W-62-43960

Elbow

36

02896-11008

O-Ring

37

07002-11423

O-Ring

38

20G-60-41121

Block

39

07000-12011

O-Ring

40

702-21-07010

Valve Assembly

41

700-93-11320

O-Ring

42

07000-12011

O-Ring

43

203-60-62220

Bolt

44

01010-80860

Bolt

45

01643-30823

Washer
