Запчасти Komatsu PW180-10 OPERATORґS СИДЕНЬЕ, ВОЗД. ПОДВЕСКА, ВНУТР. ЧАСТИ (/) OPERATORґS СИДЕНЬЕ, ВОЗД. ПОДВЕСКА

|$1

20J-57-51130

Seat Assembly

|$2

20K-57-31161

Seat Assembly

1

20K-57-31380

Seat

2

20K-57-31390

Seat

3

20K-57-31410

Screw

4

20K-57-31420

Nut

5

20K-57-31430

Screw

6

20K-57-31440

Rest

7

20K-57-31450

Band

8

20K-57-31460

Washer

9

20K-57-31470

Screw

10

20K-57-31480

Rivet

11

20K-57-31490

Washer

12

20K-57-31510

Washer

13

20K-57-31520

Support

14

20K-57-31530

Plate

15

20K-57-31540

Bumper

16

20K-57-31550

Spring

17

20K-57-31560

Plate

18

20K-57-31570

Rivet

19

20K-57-31580

Sheet

20

20K-57-31590

Block

21

20K-57-31610

Box

22

20K-57-31620

Cover Kit

23

20K-57-31630

Bracket Kit

24

20K-57-31640

Rivet

25

20K-57-31650

Washer

26

20K-57-31660

Cover

27

20K-57-31670

Bearing

28

20K-57-31680

Spring

29

20K-57-31690

Plate

30

20K-57-31710

Screw

31

20K-57-31720

Screw

32

20K-57-31730

Nut

33

20K-57-31740

Lever

34

20K-57-31750

Handle

35

20K-57-31760

Plate

36

20K-57-31770

Screw

37

20K-57-31780

Cover

38

20K-57-31790

Seat

39

20K-57-31810

Sheet

40

20K-57-31820

Latch

41

20K-57-31830

Cover

42

20K-57-31840

Handle

43

20K-57-31850

Handle

44

20K-57-31860

Rest

45

20K-57-31870

Bushing

46

20K-57-31880

Cover

47

20K-57-31890

Screw

48

20K-57-31910

Rivet

49

20K-57-31930

Rod

50

20K-57-31940

Spring

51

20K-57-31950

Bushing

52

20K-57-31960

Screw

53

20K-57-31970

Lever

54

20K-57-31980

Arm Rest

55

20K-57-31990

Arm Rest

56

20K-57-32110

Rail Kit

57

20K-57-32120

Screw

58

20K-57-32130

Screw

59

20K-57-32140

Seat Belt Kit

60

20K-57-32160

Band

61

20K-57-32170

Band

62

20K-57-32180

Cover

63

20K-57-32190

Cable

64

20K-57-32210

Screw

65

20E-57-41140

Plate

66

02215-10710

Nut

67

02030-70738

Bolt

68

02030-70729

Bolt

69

424-00-H0280

Protection Cap
