Запчасти Komatsu PW180-10 ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН, 8-СЕКЦИОНН., ДЛЯ ONE-ЧАСТИ СТРЕЛА, ВНУТР. ЧАСТИ (/9) ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН, 8-СЕКЦИОНН., ДЛЯ ONE-ЧАСТИ СТРЕЛА, ВНУТР. ЧАСТИ

|$1

723-58-18800

Control Valve

2

144-14-54610

O-Ring

3

723-56-31730

O-Ring

4

723-46-18720

O-Ring

5

723-56-31740

Ring, Back-Up

6

07000-11008

O-Ring

10

723-36-15240

Spring

11

723-36-15250

Case

12

723-56-32840

Case

13

07000-13042

O-Ring

14

723-56-32860

Seal

15

01252-60820

Bolt

16

723-56-31630

Plug

17

07002-11623

O-Ring

18

723-56-33660

Filter

19

723-56-33670

Plug

20

07002-13034

O-Ring

21

07000-12021

O-Ring

23

723-50-57100

Plug Assembly

24

07002-11423

O-Ring

25

07000-11004

O-Ring

26

07001-01004

Ring, Back-Up

27

723-56-33650

Plug

28

07000-11006

O-Ring

29

07001-01006

Ring, Back-Up

30

07000-11008

O-Ring

31

708-8E-16160

Plug

32

07002-11023

O-Ring

33

723-56-33990

Union

34

07000-13024

O-Ring

35

02896-11018

O-Ring

36

723-56-33660

Filter

37

723-56-33740

Plug

38

07002-13034

O-Ring

39

07000-12021

O-Ring

40

723-56-33610

Filter

41

07000-13024

O-Ring

42

07001-03024

Ring, Back-Up

43

07000-13022

O-Ring

44

07002-13334

O-Ring

45

708-21-12541

Plug

46

723-50-11180

Stud

47

01643-31232

Washer

48

01580-11210

Nut

49

01252-60850

Bolt
