Запчасти Komatsu PW170ES-6K ТРАНСМИССИЯ (ВНУТР. ЧАСТИ) (/) F СИЛОВАЯ ПЕРЕДАЧА

|1

20G-14-K1200

TRANSMISSION ASSEMBLY

|1

20G-14-K3102

TRANSMISSION ASSEMBLY

|1

20G-14-K3101

TRANSMISSION ASSEMBLY

1

20G-14-K3220

PLATE,(FOR SHIPPING)

2

20G-14-K3210

SCREW,(FOR SHIPPING)

3

20G-14-K3550

FLANGE

|3

20G-14-K3240

FLANGE

4

20E-14-K1550

BREATHER

|4

20G-14-K3190

PLUG

5

20G-14-K3160

O-RING

6

20G-14-K3230

BOLT

7

20E-14-K1360

BEARING

|7

20G-14-K3490

BEARING

8

20G-14-K3330

O-RING

|8

20G-14-K3330

O-RING

8A

20G-14-K3560

O-RING

|8A

20G-14-K3330

O-RING

9

20G-14-K3410

SPRING,DISK

10

20G-14-K3180

SPACER

11

20G-14-31310

SLEEVE

|11

20G-14-K3340

SLEEVE

12

20G-14-K3320

O-RING

13

20G-14-K3350

PISTON,CLUTCH

14

20G-14-K3360

DISC

|14

20G-14-K3360

DISC

15

20G-14-K3370

DISC

|15

20G-14-K3370

DISC

16

20G-14-K3610

SHAFT,INPUT

|16

20G-14-K3420

SHAFT,INPUT

17

20G-14-K3390

RING,SNAP

18

20G-14-31320

PLATE,DRIVE

|18

20G-14-K3380

PLATE,DRIVE

19

20G-14-K3460

WASHER

20

20G-14-K3450

BEARING

21

20G-14-K3440

WASHER

22

20E-14-K1620

BOLT

|22

20G-14-K3170

BOLT

23

20G-14-K3470

HOUSING,CLUTCH

24

20G-14-K3430

SEAL,OIL

25

20G-14-K3480

SHAFT,OUTPUT

26

20E-14-K1510

PLUG
