Запчасти Komatsu PW170ES-6K МОТОР ПОВОРОТА (/) (ДЛЯ ВРАЩАЮЩ. РУКОЯТИ) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

205-966-5903

SWING MOTOR ASSEMBLY

1

TZ902S2002-01

CASE

2

TZ501S2019-00

GAUGE,OIL

3

07000-12014

O-RING

4

TZW49-13235

O-RING

5

01252-31035

BOLT

6

TZ900S2018-00

SHAFT

7

06000-06204

BEARING,BALL

8

TZSB-204011

SEAL,OIL

9

TZ850A2003-00

PLATE,SWASH

10

TZ800A2017-00

PIN

11

TZ860A2030-00

PISTON ASSEMBLY

12

TZ850A2007-00

PLATE

13

TZ800A2008-00

BALL,THRUST

14

TZ850A2011-00

WASHER

15

TZ860A2004-00

BLOCK,CYLINDER

16

TZPP0025-12

PIN,DOWEL

17

TZ880A2014-01

SPRING

18

TZ907S2010-00

WASHER

19

TZIR004018

RING,SNAP

20

TZ902S2015-00

DISC

21

TZ800A2016-00

PLATE

22

TZ902S2012-01

PISTON

23

TZW28-03127

O-RING

24

TZ501S2021-01

SPRING

25

TZ902S2001-03

FLANGE,REAR

26

TZ501S2033-00

ORIFICE

27

TZ000B2101

BLEEDER

28

06000-06202

BEARING,BALL

29

TZ860A2009-00

PLATE,TIMING

30

TZPP0040-10

PIN,DOWEL

31

TZW27-03123

O-RING

32

TZW40-13177

O-RING

33

TZPP0080-25

PIN,DOWEL

34

01252-31035

BOLT
