Запчасти Komatsu PW170ES-6K РУКОЯТЬ (ДЛЯ ВРАЩАЮЩ. РУКОЯТИ) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20G-966-K100

ARM ASSEMBLY,ROTATING

1

20G-966-K120

ARM ASSEMBLY,UPPER

2

07020-00900

FITTING,GREASE

3

21K-70-32120

BUSHING

4

07145-00080

SEAL,DUST

5

21K-70-22120

PIN

6

21K-70-22150

SPACER, 1.0MM

7

205-70-66580

PLATE

8

01010-51230

BOLT

9

01643-31232

WASHER

10

20G-966-K160

CIRCLE,SWING

11

04020-01842

PIN

12

205-966-7260

SEAL

13

01011-62210

BOLT

14

01011-62210

BOLT

15

20G-966-K141

ARM ASSEMBLY,LOWER

16

07020-00000

FITTING,GREASE

17

21K-70-12170

BUSHING

18

21K-70-22130

BUSHING

19

21K-70-12180

SEAL

20

21K-70-12151

PIN

21

203-70-24170

SPACER, 1.0MM

22

205-70-66580

PLATE

23

01010-81230

BOLT

24

01643-31232

WASHER

25

20G-966-K790

COVER

26

01010-81225

BOLT

27

01643-31232

WASHER
