Запчасти Komatsu PW170ES-6K ЦИЛИНДР РУКОЯТИ(ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ)(№K-K) T РАБОЧЕЕ ОБОРУДОВАНИЕ

G1

20G-63-K1501

CYLINDER ASSEMBLY,ARM

|1

21P-63-K1711

CYLINDER ASSEMBLY

1

21K-63-64140

CYLINDER

2

21K-63-64120

ROD,PISTON

3

707-27-12620

HEAD,CYLINDER

4

707-36-12411

PISTON

5

707-71-60901

PLUNGER

6

07165-15860

NUT

7

707-71-60200

PLUNGER

8

707-71-91270

CAP

9

04260-00635

BALL,STEEL

10

707-71-32620

COLLAR

11

01010-81670

BOLT

12

01643-51645

WASHER

13

707-56-85510

SEAL,DUST

14

07179-13099

RING,SNAP

15

707-51-85030

PACKING

16

707-51-85630

RING,BUFFER

17

07000-15115

O-RING

18

07001-05115

RING,BACK-UP

19

707-52-90600

BUSHING

20

707-44-12180

RING,PISTON

21

707-39-12110

RING,WEAR

22

707-44-12911

RING

23

707-76-80230

BUSHING

24

07145-00080

SEAL,DUST

25

07020-00675

FITTING,GREASE

26

20G-62-K1880

TUBE

27

07372-21045

BOLT

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07000-13030

O-RING

31

20G-62-K1890

TUBE

32

707-88-95861

BRACKET

33

707-88-99240

BAND

34

01010-81035

BOLT

35

01643-31032

WASHER

36

07283-22738

CLIP

37

01643-31032

WASHER

38

01599-01011

NUT

39

20G-62-K1910

BRACKET

40

707-88-99210

BAND

41

01010-81035

BOLT

42

01643-31032

WASHER

43

07283-22738

CLIP

44

01643-31032

WASHER

45

01599-01011

NUT
