Запчасти Komatsu PW170ES-6K ЦИЛИНДР СТРЕЛЫ(ЛЕВ.) (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ)(№K-K8) T РАБОЧЕЕ ОБОРУДОВАНИЕ

G1

20G-63-K1801

CYLINDER ASSEMBLY,BOOM

|1

20G-63-K1410

CYLINDER ASSEMBLY

1

20G-63-K1460

HEAD,CYLINDER

2

20G-63-K1470

PISTON

3

20G-63-K1450

ROD ASSEMBLY,PISTON

4

707-76-80230

BUSHING

5

07145-00080

SEAL,DUST

6

20G-63-K1420

SHELL ASSEMBLY

7

07145-00070

SEAL,DUST

8

707-76-70330

BUSHING

9

20G-63-K1480

SCREW

10

20G-63-K1490

PLUG

11

707-52-90600

BUSHING

12

707-51-85630

RING,BUFFER

13

707-56-85510

SEAL,DUST

14

707-51-85030

PACKING,ROD

15

07000-15115

O-RING

16

07001-05115

RING,BACK-UP

17

707-44-12911

RING

18

707-44-12180

RING,PISTON

19

707-39-12110

RING,WEAR

20

07179-13099

RING,SNAP

21

07020-00675

FITTING,GREASE

22

01010-81670

BOLT

23

01643-51645

WASHER

24

707-71-60901

PLUNGER

25

20G-63-K1530

COLLAR

26

20G-62-K7030

TUBE

27

07000-13025

O-RING

28

01010-50850

BOLT

29

01643-50823

WASHER

30

20G-63-K7010

TUBE

31

07372-21035

BOLT

32

01643-51032

WASHER

33

07000-13030

O-RING

34

20G-62-K8020

BRACKET

35

707-88-99210

BAND

36

01010-81030

BOLT

37

01643-51032

WASHER

38

01010-51035

BOLT

39

01643-51032

WASHER

40

702-21-08021

PILOT VALVE ASSEMBLY

41

07372-21055

BOLT

42

01643-51032

WASHER

43

07372-21060

BOLT

44

01643-51032

WASHER

45

07000-13030

O-RING

46

20G-63-K3210

FLANGE

47

01252-40635

BOLT

48

07000-02021

O-RING

49

07230-20210

UNION

50

07002-01423

O-RING

51

07040-11409

PLUG

52

07002-01423

O-RING

53

07235-10315

ELBOW

54

07002-02034

O-RING
