Запчасти Komatsu PW170ES-6K МОТОР ПОВОРОТА(№K7-) N ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

21P-60-K1183

MOTOR ASSEMBLY,SWING

|1

21P-60-K1182

MOTOR ASSEMBLY,SWING

1

21P-60-K4760

HOUSING

2

21P-60-K1250

PLATE,VALVE

3

21P-60-K2710

PLUG

4

21P-60-K4770

HOUSING

5

21P-60-K1260

O-RING

6

21P-60-K1270

O-RING

7

21P-60-K1280

O-RING

8

21P-60-K4780

SEAL

9

21P-60-K4790

SEAL

|9

21P-60-K1290

SEAL

10

21P-60-K4810

SPACER,(NOT SHOWN)

11

21P-60-K2740

RING

12

21P-60-K4820

RING

13

21P-60-K2750

SEAL

14

21P-60-K4830

SHAFT

15

21P-60-K2770

PIN

16

21P-60-K4840

BARREL

17

21P-60-K4850

SUPPORT

18

21P-60-K2820

PISTON ASSEMBLY

|18

21P-60-K2820

PISTON ASSEMBLY

19

21P-60-K1310

RING

|19

21P-60-K1310

RING,PISTON

20

21P-60-K4860

RING,NEEDLE

21

21P-60-K1360

BEARING,BALL

22

21P-60-K4870

BEARING

23

21P-60-K4880

SPACER, 2.35MM

|23

21P-60-K4890

SPACER, 2.4MM

|23

21P-60-K4910

SPACER, 2.45MM

|23

21P-60-K4920

SPACER, 2.5MM

|23

21P-60-K4930

SPACER, 2.55MM

|23

21P-60-K4940

SPACER, 2.6MM

|23

21P-60-K4950

SPACER, 2.65MM

|23

21P-60-K4960

SPACER, 2.7MM

|23

21P-60-K4970

SPACER, 2.75MM

|23

21P-60-K4980

SPACER, 2.8MM

|23

21P-60-K4990

SPACER, 2.85MM

|23

21P-60-K5110

SPACER, 2.9MM

|23

21P-60-K5120

SPACER, 2.95MM

24

21P-60-K2670

RING,RETAINER

25

21P-60-K1410

SHIM, 0.2MM

|25

21P-60-K2880

SHIM, 0.4MM

|25

21P-60-K2890

SHIM, 0.6MM

|25

21P-60-K2910

SHIM, 0.8MM

|25

21P-60-K2920

SHIM, 1.0MM

|25

21P-60-K2930

SHIM, 1.0MM

26

21P-60-K2940

SCREW

27

21P-60-K4360

HOUSING

28

21P-60-K1330

O-RING

29

21P-60-K4370

PLUG

30

21P-60-K5150

CARTRIDGE,VALVE

|30

21P-60-K1340

CARTRIDGE,VALVE

31

21P-60-K4380

PLUG

32

21P-60-K1350

VALVE,CHECK
