Запчасти Komatsu PW170ES-6K ПЕРЕГОРОДКА. (КАБИНА)(№K-K8) M ЧАСТИ КОРПУСА

|1

21P-54-K3173

COVER

1

21P-54-K3184

FRAME

2

21P-54-K3194

SHEET

3

21P-54-K3212

SHEET

4

01010-81230

BOLT

5

124-54-26540

WASHER

6

01010-81230

BOLT

7

01643-31232

WASHER

8

21P-54-K3351

COVER

9

21P-54-K3341

COVER

10

01010-51230

BOLT

11

01643-31232

WASHER

12

20G-54-K4651

COVER

12A

20G-54-K4660

COVER

12B

20G-54-K4670

COVER

12C

01010-81020

BOLT

12D

01643-31023

WASHER

13

20G-54-K4680

SHEET

14

21P-54-K3283

SHEET

15

21P-54-K3292

SHEET

16

21P-54-K2440

SHEET

17

21P-54-K3840

SEAL

18

21P-54-K3852

SEAL

19

21P-54-K3960

SHEET

20

01010-51230

BOLT

21

01643-31232

WASHER

22

01010-51230

BOLT

23

01643-31232

WASHER

24

01010-51230

BOLT

25

01643-31232

WASHER

26

01010-51220

BOLT

27

01643-31232

WASHER

28

21P-54-K3752

COVER ASSEMBLY

29

21P-54-K3770

SHEET

30

21P-54-K2430

SHEET

31

21P-54-K3690

SHEET

32

21P-54-K3730

SHEET

33

20Y-54-12320

CATCH

34

01010-81230

BOLT

35

01643-31232

WASHER
