Запчасти Komatsu PW170ES-6K КАПОТ(№K-.) M ЧАСТИ КОРПУСА

|1

20G-54-K2713

HOOD ASSEMBLY

|1

20G-54-K2712

HOOD ASSEMBLY

|1

20G-54-K2481

HOOD ASSEMBLY

1

20G-54-K2722

HOOD

|1

20G-54-K2721

HOOD

|1

20G-54-K2431

HOOD

2

20G-54-K2731

COVER

|2

20G-54-K2730

COVER

|2

20G-54-K2440

COVER

3

21P-54-K5450

HINGE (WELDED)

|3

207-54-K2450

HINGE (WELDED)

4

01010-81220

BOLT

5

01643-31232

WASHER

6

20G-54-K2580

SHEET

7

20G-54-K2593

SHEET

|7

20G-54-K2592

SHEET

|7

20G-54-K2590

SHEET

8

20G-54-K2653

SHEET

|8

20G-54-K2652

SHEET

|8

20G-54-K2650

SHEET

9

20G-54-K2661

SHEET

|9

20G-54-K2660

SHEET

10

20G-54-K2671

SHEET

|10

20G-54-K2670

SHEET

11

20G-54-K2470

SHEET

12

205-54-76260

CATCHER

13

01010-80825

BOLT

14

01643-30823

WASHER

15

205-54-67660

SUPPORT

16

01010-80825

BOLT

17

01643-30823

WASHER

18

20E-68-K1010

SPRING

19

01580-00806

NUT

20

01643-30823

WASHER

21

20G-54-K2450

SEAL

22

20G-54-K2460

SEAL

23

20E-01-K1370

CAP

|23

20E-01-K1520

CAP

24

203-01-61331

PIPE

|24

20E-01-K2130

PIPE,(WITHOUT RAIN CAP)

25

01010-81225

BOLT

26

01643-31232

WASHER

27

01010-81230

BOLT

|27

01010-81230

BOLT

28

01643-31232

WASHER

|28

01643-31232

WASHER

29

124-54-26540

WASHER
