Запчасти Komatsu PW170ES-6K ПЕДАЛЬ ТОРМОЗА (ВНУТР. ЧАСТИ) (/)(№K-) K КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

20E-60-K4722

PEDAL ASSEMBLY

|1

20E-60-K6150

VALVE ASSEMBLY

1

20E-60-K5530

BOX

2

20E-60-K5580

O-RING

3

20E-60-K5210

BUSHING

4

20E-60-K5770

O-RING

5

20E-60-K5420

SPINDLE

6

20E-60-K5410

ROD

7

20E-60-K4960

BAR

8

20E-60-K5160

ROD

9

20E-60-K5180

BUSHING

10

20E-60-K5870

PUSHER

11

20E-60-K5910

O-RING

12

20E-60-K5370

SPRING

13

20E-60-K5350

PLATE

14

20E-60-K5860

WASHER

15

20E-60-K5630

RING

16

20E-60-K5650

O-RING

17

20E-60-K5810

O-RING

18

20E-60-K5190

ROD

19

20E-60-K5260

ROD

20

20E-60-K5690

O-RING

21

20E-60-K5620

O-RING

22

20E-60-K5430

FITTING

23

20E-60-K5280

FITTING

24

20E-60-K5830

WASHER

25

20E-60-K5270

ROD

26

20E-60-K5790

O-RING

27

20E-60-K5340

RETAINER

28

20E-60-K5330

ROD

29

20E-60-K5220

SPRING

30

20E-60-K5290

SEAT

31

20E-60-K5310

ROD

32

20E-60-K4940

CLIP

33

20E-60-K5890

SCREW

34

20E-60-K4970

SPRING

35

20E-60-K5740

O-RING

36

20E-60-K5680

SELECTOR

37

20E-60-K5360

SPRING

38

20E-60-K5540

HOUSING

39

20E-60-K5930

WASHER

40

20E-60-K5840

NUT

41

20E-60-K5590

WASHER

42

20E-60-K5380

BOLT

43

20E-60-K5940

WASHER

44

20E-60-K5390

CAP

45

20E-60-K5710

SCREW

46

20E-60-K5850

SCREW

47

20E-60-K6890

SOLENOID VALVE ASSEMBLY

48

20E-60-K6280

SOLENOID VALVE

49

20E-60-K5780

O-RING

50

20E-60-K5720

SCREW
