Запчасти Komatsu PW170ES-6K КЛАПАН РУЛЕВОГО УПРАВЛЕНИЯ (ВНУТР. ЧАСТИ) K КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20G-60-K2271

VALVE ASSEMBLY,STEERING

2

20G-60-K3330

RING,SEAL (KIT)

3

20G-60-K3340

BOLL

4

20G-60-K3350

BUSHING

5

20G-60-K3360

O-RING (KIT)

6

20G-60-K3370

BEARING

7

20G-60-K3380

RING

8

20G-60-K3390

PIN

9

20G-60-K3410

SPRING SET

10

20G-60-K3420

SHAFT

11

20G-60-K3430

O-RING (KIT)

12

20G-60-K3440

PLATE

13

20G-60-K3450

GEAR

14

20G-60-K3460

O-RING (KIT)

15

20G-60-K3470

COVER,END

16

20G-60-K3480

WASHER (KIT)

17

20G-60-K3490

SCREW

18

20G-60-K3510

PLATE,NAME

19

20G-60-K3520

VALVE ASSEMBLY,RELIEF

20

20G-60-K3530

SPRING

21

20G-60-K3540

VALVE ASSEMBLY

22

20G-60-K3550

BOLL

23

20G-60-K3560

BUSHING

24

20G-60-K3570

VALVE

25

20G-60-K3580

BOLL

26

20G-60-K3590

PIN

27

20G-60-K3610

SHAFT

28

20G-60-K3620

PLATE

29

20G-60-K3630

PLATE

30

20G-60-K3640

HOUSING

31

20G-60-K3650

SPRING

32

20G-60-K3660

PIN

33

20G-60-K3670

VALVE

KIT

20G-60-K3680

REPAIR PARTS
