Запчасти Komatsu PW170ES-6K ОСНОВН. НАСОС (ВНУТР. ЧАСТИ) (/) H ГИДРАВЛИКА

Схема запчастей Komatsu PW170ES-6K - ОСНОВН. НАСОС (ВНУТР. ЧАСТИ) (/) H ГИДРАВЛИКА
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
24
24
25
26
26
27

Артикул

Название

Примечание

Количество

|1

20G-60-K1900

PUMP ASSEMBLY,MAIN

|1

20G-60-K1600

PUMP ASSEMBLY,MAIN

1

21P-60-K3040

SHAFT ASSEMBLY

2

21P-60-K3050

PLATE ASSEMBLY

3

21P-60-K3060

REGULATOR ASSEMBLY

|4

21P-60-K3070

ROD ASSEMBLY

4

21P-60-K4190

PISTON

5

21P-60-K4210

ROD

|5

21P-60-K4220

ROD

|5

21P-60-K4230

ROD

6

21P-60-K4240

SPRING

7

21P-60-K4250

BUSHING

|8

21P-60-K3080

ROD ASSEMBLY

8

21P-60-K4260

PISTON

9

21P-60-K4270

ROD

10

21P-60-K4280

SPRING

|11

21P-60-K3090

PLATE ASSEMBLY

11

21P-60-K4290

FLANGE

12

21P-60-K4310

HUB

13

21P-60-K4320

BOLT

14

21P-60-K4330

O-RING (KIT A)

15

21P-60-K4340

O-RING (KIT A)

16

21P-60-K3110

HOUSING

17

21P-60-K3120

PIN

18

21P-60-K3130

IMPELLER

19

21P-60-K3140

PIN

20

21P-60-K3150

NUT (KIT A)

21

21P-60-K3160

PLUG (KIT A)

22

21P-60-K3170

BOLT

23

21P-60-K3180

O-RING (KIT A)

24

21P-60-K3190

PLUG (KIT A)

25

21P-60-K3210

PIN

26

21P-60-K3220

RING,RETAINER

27

21P-60-K3230

SCREW

|27

20G-60-K2720

PLUG

KIT A

21P-60-K4510

SERVICE KIT,MAIN PUMP

Выбрано товаров: 36
