Запчасти Komatsu PW170ES-6K ОСНОВН. КЛАПАН (ВНУТР. ЧАСТИ) (/) H ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
|1
723-38-15600
VALVE ASSEMBLY
|1
723-38-15302
VALVE ASSEMBLY
|1
723-31-02700
BODY SUB ASSEMBLY
|1
723-31-00600
BODY SUB ASSEMBLY
1
07000-12014
O-RING
2
07000-13028
O-RING
3
07000-13035
O-RING
4
BODY
5
SPOOL
6
723-36-15130
PLUG
7
07002-10823
O-RING
8
708-7T-16460
BALL
9
723-36-15120
RETAINER
10
723-36-14110
SPRING
11
723-36-15110
CASE
12
723-36-15170
O-RING
13
01252-30622
BOLT
14
01641-20608
WASHER
|15
723-36-48100
VALVE ASSEMBLY
15
SLEEVE
16
VALVE
17
SEAT
18
POPPET
19
PLUG
20
SCREW
21
NUT
22
NUT
23
SPRING
24
SPRING
25
PLATE
26
CAP
27
SEAL
28
SEAL
29
700-80-61260
O-RING
30
700-80-61430
RING
31
07002-13034
O-RING
32
O-RING
33
RING
34
O-RING
35
RING,BACK-UP
|36
723-30-66200
VALVE ASSEMBLY
36
PLUG
37
SEAT
38
BALL
39
07002-12434
O-RING
40
07000-12012
O-RING
41
07001-02012
RING,BACK-UP
42
07000-12010
O-RING
43
07001-02010
RING
|44
723-36-40400
VALVE ASSEMBLY
44
723-36-41510
PISTON SUB ASSEMBLY
45
723-36-41310
SLEEVE
46
723-36-41960
SPRING
47
700-80-61260
O-RING
48
700-80-61430
RING
49
07002-13034
O-RING
50
723-36-41110
VALVE
Выбрано товаров: 57
