Запчасти Komatsu PW170ES-6K ГИДР. БАК.(№K-K999) H ГИДРАВЛИКА

|1

20G-60-K1500

TANK ASSEMBLY,HYDRAULIC OIL

1

TANK

2

21P-60-K1220

PLATE ASSEMBLY

3

01010-81265

BOLT

4

01643-31232

WASHER

5

07000-05195

O-RING

6

07063-01100

ELEMENT

7

203-60-52260

STRAINER

8

203-60-52250

VALVE ASSEMBLY

9

175-60-27340

SPRING

10

07000-05155

O-RING

11

COVER

12

01010-81225

BOLT

13

01643-31232

WASHER

14

203-60-56250

STRAINER

15

203-60-56270

O-RING

16

20E-60-K1220

ROD

17

12R-60-11230

SPRING

18

07000-05180

O-RING

19

COVER

20

01010-81235

BOLT

21

01643-31232

WASHER

22

205-60-51460

GASKET

23

201-60-12171

FILLER

24

01220-40516

SCREW

25

01601-20513

WASHER

26

201-60-12190

CAP ASSEMBLY

27

07270-00895

TUBE

28

07285-00095

CLIP

29

08036-01214

CLIP

30

203-60-31160

TUBE

31

203-60-31100

ELBOW ASSEMBLY

32

08036-01214

CLIP

33

01010-81220

BOLT

34

01643-31232

WASHER

35

01010-81635

BOLT

36

01643-31645

WASHER

37

07040-12412

PLUG

38

07002-12434

O-RING
