Запчасти Komatsu PW170ES-6K МОТОР ХОДА (ЗАДН.) (KPH) (ВНУТР. ЧАСТИ) (/)(№K9-) F СИЛОВАЯ ПЕРЕДАЧА

|1

20G-60-K5580

MOTOR ASSEMBLY,TRAVEL, REAR (30KPH)

|1

20G-60-K5740

CONTROL ASSEMBLY

|1

20G-60-K6220

CONTROL ASSEMBLY

1

20G-60-K6250

PLATE,END

2

20G-60-K6260

PISTON

3

20G-60-K6270

PIN

4

20G-60-K6280

PIN

5

20G-60-K6290

O-RING

6

20G-60-K6310

O-RING

7

20G-60-K6320

TORCON-STEPS

8

20G-60-K6330

O-RING

9

20G-60-K6340

PIN,DOWEL

10

20G-60-K6350

SCREW

11

20G-60-K6360

PLUG

12

20G-60-K6370

PLUG

|13

20G-60-K6230

CONTROL ASSEMBLY

13

20G-60-K6380

VALVE ASSEMBLY

14

20G-60-K6480

VALVE ASSEMBLY

15

20G-60-K6490

RING,SAFETY

16

20G-60-K6510

SHIM

17

20G-60-K6520

SHIM

|18

20G-60-K6530

SEAL KIT

18

20G-60-K6540

O-RING

19

20G-60-K6550

O-RING

20

20G-60-K6560

RING,BACK-UP

21

20G-60-K6390

HOUSING

22

20G-60-K6370

PLUG

|23

20G-60-K6410

CHECK VALVE ASSEMBLY

23

20G-60-K6570

SEAT

24

20G-60-K6580

POPPET

25

20G-60-K6590

SPRING

26

20G-60-K6420

SCREW

27

20G-60-K6430

O-RING

28

20G-60-K6440

O-RING

29

20G-60-K6450

O-RING

30

20G-60-K6460

RING,BACK-UP

31

20G-60-K6470

PLUG

|32

20G-60-K6240

COVER ASSEMBLY

32

20G-60-K6610

COVER

33

20G-60-K6620

SCREW

34

20G-60-K6630

PLUG

35

20G-60-K6640

PLUG

36

20G-60-K6650

VALVE,CHECK

37

20G-60-K6660

O-RING

38

20G-60-K6670

O-RING

39

20G-60-K6680

RING,BACK-UP

40

20G-60-K6690

SCREW,THROTTLE
