Запчасти Komatsu PW170ES-6K-KA МОТОР ХОДА (ЗАДН.) (KPH) (ВНУТР. ЧАСТИ) (/)(№K77-) СИЛОВАЯ ПЕРЕДАЧА

|1

20G-60-K6810

MOTOR ASS'Y,TRAVEL¤ REAR (20KPH)

|1

20G-60-K5730

MOTOR ASS'Y

|1

20G-60-K5750

ROTARY ASS'Y

1

20G-60-K5820

SHAFT,DRIVE

2

20G-60-K5830

PISTON

3

20G-60-K5840

RING

4

20G-60-K5850

CYLINDER

5

20G-60-K5860

LENS,CONTROL

6

20G-60-K5870

PIN,PRESSURE

7

20G-60-K5880

PLATE,RETAINING

8

20G-60-K5890

FLANGE

9

20G-60-K5910

RING,TUNING

10

20G-60-K5920

SPRING

11

20G-60-K5930

DISC

12

20G-60-K5940

SHIM

13

20G-60-K5950

SCREW,DISTANCE

14

20G-60-K5960

BEARING

15

20G-60-K5970

BEARING

16

20G-60-K5980

SEAL

17

20G-60-K5990

O-RING

18

20G-60-K6110

RING,SNAP

19

20G-60-K6120

RING,SNAP

20

20G-60-K6130

SHIM

21

20G-60-K6140

SCREW

|22

20G-60-K5760

SCREW ASS'Y

22

20G-60-K6190

SCREW

23

20G-60-K6210

NUT,CAP

24

20G-60-K6170

NUT

25

20G-60-K6180

O-RING

|26

20G-60-K5770

SCREW ASS'Y

26

20G-60-K6150

SCREW

27

20G-60-K6160

NUT,CAP

28

20G-60-K6170

NUT

29

20G-60-K6180

O-RING

30

20G-60-K5780

HOUSING

31

20G-60-K5790

PLUG

32

20G-60-K5810

PLUG

33

20G-60-K5740

CONTROL ASS'Y
