Запчасти Komatsu PW170ES-6K-KA МОТОР ХОДА (ПЕРЕДН.) (ВНУТР. ЧАСТИ) (/) СИЛОВАЯ ПЕРЕДАЧА

|1

20G-60-K3280

MOTOR ASS'Y,TRAVEL¤ FRONT (20KPH)

|1

20G-60-K3880

MOTOR ASS'Y,TRAVEL¤ FRONT (30KPH)

|1

20G-60-K3090

MOTOR ASS'Y

|1

20G-60-K3920

CONTROL

|1

20G-60-K4110

CONTROL

1

20G-60-K2630

HOUSING

2

20G-60-K2640

BUSHING

3

20G-60-K2650

PISTON

4

20G-60-K2660

BUSHING

5

20G-60-K2670

BOLT

6

20G-60-K4290

SPRING

7

20G-60-K2690

SPRING

8

20G-60-K4310

O-RING (K1)

9

20G-60-K2710

SCREW

10

20G-60-K4320

SCREW (K1)

11

20G-60-K2730

RING

12

20G-60-K1490

STUD

13

20G-60-K2740

PIN

14

20G-60-K1520

NUT

15

20G-60-K2750

PIN

16

20G-60-K2760

DISC

|17

20G-60-K4120

COVER ASS'Y

17

20G-60-K4330

COVER

18

20G-60-K4340

SCREW

19

20G-60-K4350

SCREW

20

20G-60-K4360

O-RING (K1)

21

20G-60-K4320

SCREW (K1)

22

20E-60-K2670

VALVE ASS'Y

23

20G-60-K4140

PLATE

24

20G-60-K4150

PISTON

25

20G-60-K4160

TRUNNION

26

20G-60-K4170

RETAINER

27

20G-60-K4180

PIN

28

20G-60-K4190

PLUG

29

20G-60-K2560

SCREW

30

20G-60-K4210

SCREW

31

20G-60-K4220

O-RING (K1)

32

20G-60-K4230

O-RING (K1)

33

20G-60-K4240

O-RING

34

20G-60-K4250

SCREW

35

20G-60-K4260

RING (K1)

36

20G-60-K2580

PIN

37

20G-60-K4270

PIN

38

20G-60-K2590

PIN

39

20G-60-K4280

O-RING (K1)

40

20G-60-K3950

SCREW (K1)

K1

20G-60-K4390

SEAL KIT,MOTOR

K2

20G-60-K4410

SEAL KIT,DRIVE SHAFT
