Запчасти Komatsu PW170ES-6K-KA МОТОР ХОДА (ПЕРЕДН.) (ВНУТР. ЧАСТИ) (/) СИЛОВАЯ ПЕРЕДАЧА

|1

20G-60-K3280

MOTOR ASS'Y,TRAVEL¤ FRONT (20KPH)

|1

20G-60-K3880

MOTOR ASS'Y,TRAVEL¤ FRONT (30KPH)

|1

20G-60-K3090

MOTOR ASS'Y,VARIABLE

|1

20G-60-K3910

ROTARY ASS'Y

|1

20G-60-K4010

ROTARY ASS'Y

1

20G-60-K2430

CYLINDER

2

20G-60-K4060

CONTROL

3

20G-60-K4070

PIN,CENTER

4

20G-60-K2450

PISTON

5

20G-60-K4080

SHIM

6

20G-60-K4090

SPRING

7

20G-60-K2480

PLATE

8

20G-60-K2490

RING

9

20G-60-2510

SCREW

10

20G-60-K4020

SHAFT,DRIVE

11

20G-60-K4030

SHIM

12

20G-60-K4040

PLATE,BACK UP

13

20G-60-K4050

RING,RETAINER

14

20G-60-K2360

BEARING

15

20G-60-K2370

BEARING

16

20G-60-K3920

CONTROL

17

20E-60-K1930

STUD

18

20G-60-K3940

HOUSING

19

20G-60-K3950

SCREW (K1)

20

20G-60-K3960

RING,RETAINER

21

20G-60-K1260

RING (K1¤K2)

22

20G-60-K3970

PLATE (K1¤K2)

23

20G-60-K3980

O-RING (K1)

24

20G-60-K3950

SCREW (K1)

25

20G-60-K1480

NUT (K1)

26

20E-60-K2670

VALVE ASS'Y,BRAKE
