Запчасти Komatsu PW170ES-6K-KA ТРАНСМИССИЯ (ВНУТР. ЧАСТИ) (/) СИЛОВАЯ ПЕРЕДАЧА

|1

20G-14-K1200

TRANSMISSION ASS'Y

|1

20G-14-K3102

TRANSMISSION ASS'Y

|1

20G-14-K3101

TRANSMISSION ASS'Y

1

20E-14-K1870

CASE

2

20E-14-K1550

BREATHER

3

20E-14-K1230

BOLT

4

20E-14-K1410

O-RING

5

20E-14-K1210

BOLT

6

20E-14-K1280

NUT

7

20E-14-K1430

O-RING

8

20E-14-K1240

BOLT

9

20E-14-K1930

PLUG

10

20E-14-K1310

WASHER

|10

20E-14-K1310

WASHER

11

20E-14-K1910

COVER

12

20E-14-K1610

WASHER

13

20E-14-K1490

PLUG

14

20E-14-K1320

RIVET

15

20E-14-K1520

LABEL

16

20E-14-K1740

CASE

17

20E-14-K1270

PLUG

|17

20E-14-K1270

PLUG

|17

20E-14-K1270

PLUG

18

20E-14-K1530

PIN,DOWEL

19

20E-14-K1220

BOLT

20

20E-14-K1750

COVER

21

20E-14-K1580

PLUG

22

20E-14-K1570

PAD

23

20E-14-K1790

FORK

24

20E-14-K1560

BOLT

25

20E-14-K1440

O-RING

26

20E-14-K1770

LEVER

27

20E-14-K1940

SPACER

28

20E-14-K1510

PLUG

29

20E-14-K1840

PLATE,(FOR SHIPPING)

30

20E-14-K1250

BOLT,(FOR SHIPPING)
