Запчасти Komatsu PW170ES-6K-KA ЦИЛИНДР 2-Й СТРЕЛЫ (С КЛАПАН БЕЗОПАСНОСТИ) (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ)(№K-) РАБОЧЕЕ ОБОРУДОВАНИЕ

G1

20G-63-K2101

CYLINDER ASS'Y

|1

20G-63-K1110

CYLINDER ASS'Y

1

20G-63-K1540

CYLINDER

2

20G-63-K1570

ROD

3

20G-63-K1590

HEAD

4

20G-63-K1610

PISTON

5

707-40-14870

SPACER

6

01252-31250

BOLT

7

07179-13114

RING

8

707-52-90750

BUSHING

9

176-63-56170

SEAL

10

707-51-10030

PACKING

11

707-51-10630

RING

12

707-44-16180

RING

13

707-39-16820

RING,WEAR

14

707-44-16910

RING

15

07000-12080

O-RING

16

707-35-52920

RING,BACK-UP

17

07000-15155

O-RING

18

07001-05155

RING,BACK-UP

19

01010-82085

BOLT

20

707-88-75310

WASHER

21

07020-00000

FITTING,GREASE

22

707-76-90130

BUSHING

23

207-63-76170

BUSHING

24

205-70-62180

SEAL,DUST

25

702-21-08021

PILOT VALVE ASS'Y

26

07372-21055

BOLT

27

01643-51032

WASHER

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07000-13030

O-RING

31

20G-60-K3210

FLANGE

32

01252-40635

BOLT

33

07000-02021

O-RING

34

07230-20210

UNION

35

07002-11423

O-RING

36

07040-11409

PLUG

37

07002-11423

O-RING

38

20G-62-K8130

ADAPTOR

39

07002-12034

O-RING

40

20G-62-K7080

TUBE

41

07000-13030

O-RING

42

07372-21035

BOLT

43

01643-51032

WASHER

44

20G-62-K7070

TUBE

45

07372-21060

BOLT

46

01643-51032

WASHER

47

07000-13030

O-RING

48

20G-60-K8010

BRACKET

49

07283-22236

CLIP

50

01599-01011

NUT

51

01643-31032

WASHER

52

01010-81240

BOLT

53

01643-31232

WASHER
