Запчасти Komatsu PW170ES-6K-KA ЦИЛИНДР СТРЕЛЫ(ПРАВ.) (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) (KA СПЕЦ-Я.)(№K-K999) РАБОЧЕЕ ОБОРУДОВАНИЕ

G1

20G-63-K2401

CYLINDER ASS'Y,BOOM

|G1

20G-63-K2400

CYLINDER ASS'Y,BOOM

|1

20G-63-03240

CYLINDER ASS'Y

|1

20G-63-03140

CYLINDER ASS'Y

1

707-27-12420

HEAD,CYLINDER

2

707-36-12071

PISTON

3

20G-63-52720

ROD ASS'Y,PISTON

4

707-76-80230

BUSHING

5

07145-00080

SEAL,DUST

6

20G-63-52740

SHELL ASS'Y

7

07145-00070

SEAL,DUST

8

707-76-70610

BUSHING

|8

707-76-70330

BUSHING

9

01310-01216

SCREW

10

07000-15075

O-RING

11

707-35-90930

RING

12

707-52-90610

BUSHING

13

707-51-85630

RING,BUFFER

14

707-56-85510

SEAL,DUST

15

707-51-85030

PACKING,ROD

16

07000-15110

O-RING

17

707-35-91220

RING,BACK-UP

18

707-44-12911

RING

19

707-44-12180

RING,PISTON

20

707-39-12110

RING,WEAR

21

07179-13099

RING,SNAP

22

07020-00675

FITTING,GREASE

23

01010-81670

BOLT

24

01643-51645

WASHER

25

707-71-60860

PLUNGER

26

707-71-32670

COLLAR

27

20G-62-K7041

TUBE

28

07000-13025

O-RING

29

01010-80850

BOLT

30

01643-50823

WASHER

31

20G-63-K8790

TUBE

32

07372-21045

BOLT

33

07372-21060

BOLT

34

01643-51032

WASHER

35

07000-13030

O-RING

36

20G-62-K8020

BRACKET

37

707-88-99210

BAND

38

01010-81030

BOLT

39

01643-51032

WASHER

40

01010-81035

BOLT

41

01643-51032

WASHER
