Артикул
Название
Примечание
Количество
G1
20G-63-K3200
CYLINDER ASS'Y,BOOM
|1
20G-63-03240
CYLINDER ASS'Y
1
707-27-12420
HEAD,CYLINDER
2
707-36-12071
PISTON
3
20G-63-52720
ROD ASS'Y,PISTON
4
707-76-80230
BUSHING
5
07145-00080
SEAL,DUST
6
20G-63-52740
SHELL ASS'Y
7
07145-00070
SEAL,DUST
8
707-76-70610
BUSHING
9
01310-01216
SCREW
10
07000-15075
O-RING
11
707-35-90930
RING
12
707-52-90610
BUSHING
13
707-51-85630
RING,BUFFER
14
707-56-85510
SEAL,DUST
15
707-51-85030
PACKING,ROD
16
07000-15110
O-RING
17
707-35-91220
RING,BACK-UP
18
707-44-12911
RING
19
707-44-12180
RING,PISTON
20
707-39-12110
RING,WEAR
21
07179-13099
RING,SNAP
22
07020-00675
FITTING,GREASE
23
01010-61670
BOLT
24
01643-51645
WASHER
25
707-71-60860
PLUNGER
26
707-71-32670
COLLAR
27
20G-62-K7041
TUBE
28
07000-13025
O-RING
29
01010-80850
BOLT
30
01643-50823
WASHER
31
20G-63-K7021
TUBE
32
07372-21035
BOLT
33
01643-51032
WASHER
34
07000-13030
O-RING
35
20G-62-K8020
BRACKET
36
707-88-99210
BAND
37
01010-81035
BOLT
38
01643-51032
WASHER
39
01010-81030
BOLT
40
01643-51032
WASHER
41
702-21-08021
PILOT VALVE ASS'Y
42
07372-21055
BOLT
43
01643-51032
WASHER
44
07372-21060
BOLT
45
01643-51032
WASHER
46
07000-13030
O-RING
47
20E-62-K2970
TEE
48
07002-01423
O-RING
49
07235-10315
ELBOW
50
07002-02034
O-RING
Выбрано товаров: 52
