Запчасти Komatsu PW170ES-6K-KA ПЕРЕДНИЙ МОСТ (NUCKLE И КОЛЕСА ВТУЛКА) SUSPENTION И КОЛЕСА

|1

20G-23-K1201

AXLE ASS'Y,FRONT

|1

20G-23-K1200

AXLE ASS'Y,FRONT

1

20E-23-K2550

BREATHER

2

20E-14-K1490

PLUG

3

20E-14-K1610

WASHER

4

20E-23-K1280

FITTING,GREASE

5

20E-23-K2630

BOLT

6

20E-23-K2380

PIN,KING

7

20E-23-K1420

O-RING

8

20E-23-K2070

SHIM¤ 0.1MM

|8

20E-23-K2080

SHIM¤ 0.3MM

9

20E-23-K2510

SPACER

10

20E-23-K1760

BEARING

11

20E-23-K2220

BOLT

11A

20E-22-K1150

NUT

12

20E-23-K2410

HUB,WHEEL

13

20E-23-K1430

O-RING

14

20E-23-K2860

SEAL

|14

20E-23-K2610

SEAL

15

20E-23-K2470

DISC,BRAKE

16

20E-23-K2440

GEAR

17

20E-23-K2270

RING

18

20E-23-K1770

PIN,KING

18A

20E-23-K1290

FITTING,GREASE

19

20E-23-K2570

O-RING

20

20E-23-K2450

GEAR

21

20E-23-K2480

GEAR,RING

22

20E-23-K2490

PISTON,BRAKE

23

20E-23-K1720

BOLT

24

20E-23-K2330

COLLAR

25

20E-23-K2850

PLATE

|25

20E-23-K2460

CARRIER,WHEEL

26

20E-23-K2520

SPRING

27

20E-23-K2530

PIN

28

20E-23-K2540

LOCK

29

20E-23-K1440

O-RING

30

20E-23-K1250

PLUG

31

20E-23-K2560

O-RING

32

20E-23-K2320

COLLAR

33

20E-23-K2880

HOUSING,L.H.

|33

20E-23-K2650

HOUSING,L.H.

34

20E-23-K2870

HOUSING,R.H.

|34

20E-23-K2640

HOUSING,R.H.

35

20E-23-K1730

BUSHING

36

20E-23-K1821

SEAL,OIL

|36

20E-23-K1820

SEAL,OIL

37

20E-23-K1260

NUT

38

20E-23-K1650

BOLT
