Запчасти Komatsu PW170ES-6K-KA МЕХАНИЗМ ПОВОРОТА (ВНУТР. ЧАСТИ) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

20G-26-K1111

SWING MACHINERY A.

|1

20G-26-K1110

SWING MACHINERY A.

1

21P-26-K1250

HOUSING ASS'Y

2

21P-26-K1140

SEAL

3

21P-26-K1170

BEARING,BALL

4

21P-26-K1230

SEAL,RING

5

21P-26-K1240

BEARING,BALL

6

21P-26-K0160

RETAINER

7

21P-26-K1190

WASHER

|7

21P-26-K1190

WASHER

|7

21P-26-K1190

WASHER

8

21P-26-K1210

PLUG

|8

21P-26-K1210

PLUG

|8

21P-26-K1210

PLUG

9

21P-26-K0220

TUBE

10

21P-26-K0230

ELBOW

11

21P-26-K1270

GEAR ASS'Y

12

21P-26-K1220

O-RING

13

21P-26-K0090

FLANGE

14

21P-26-K1280

SCREW

15

21P-26-K1290

SCREW

16

21P-26-K1330

GEAR ASS'Y

17

21P-26-K1310

O-RING

18

21P-26-K1340

RING,SNAP

19

21P-26-K0310

SPACER

20

21P-26-K1350

PLUG

21

21P-26-K1490

HOUSING,BRAKE

22

21P-26-K1360

SCREW

23

21P-26-K1370

O-RING

24

21P-26-K0020

SHAFT,DRIVE

25

21P-26-K0330

DISC

26

21P-26-K0320

DISC

27

21P-26-K0340

SPACER

28

21P-26-K1380

O-RING

29

21P-26-K0040

CARRIER

30

21P-26-K0350

SPRING

31

21P-26-K0030

DISC

32

21P-26-K1390

RING,SNAP

33

21P-26-K1410

O-RING

34

21P-26-K1420

WASHER

35

21P-26-K1430

ELBOW

36

21P-26-K1440

PLUG

37

21P-26-K1450

SCREW

38

21P-26-K1460

SCREW

39

21P-26-K1510

FLANGE

40

21P-26-K1470

O-RING

41

21P-26-K1480

FILLER
