Запчасти Komatsu PW170ES-6K-KA ПЕДАЛЬ ТОРМОЗА (ВНУТР. ЧАСТИ) (/)(№K-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

20E-60-K4722

PEDAL ASS'Y

|1

20E-60-K6150

VALVE ASS'Y

1

20E-60-K5530

BOX

2

20E-60-K5580

O-RING

3

20E-60-K5210

BUSHING

4

20E-60-K5770

O-RING

5

20E-60-K5420

SPINDLE

6

20E-60-K5410

ROD

7

20E-60-K4960

BAR

8

20E-60-K5160

ROD

9

20E-60-K5180

BUSHING

10

20E-60-K5870

PUSHER

11

20E-60-K5910

O-RING

12

20E-60-K5370

SPRING

13

20E-60-K5350

PLATE

14

20E-60-K5450

PLATE

15

20E-60-K5970

SCREW

16

20E-60-K5670

WASHER

17

20E-60-K5570

BRACKET

18

20E-60-K5460

SHAFT

19

20E-60-K5960

NUT

20

20E-60-K5520

WASHER

21

20E-60-K5250

LEVER

22

20E-60-K5640

SCREW

23

20E-60-K5880

SCREW

24

20E-60-K5660

NUT

25

20E-60-K6160

HOUSING

26

20E-60-K5750

SPOOL

27

20E-60-K5230

PIN

28

20E-60-K5950

NUT

29

20E-60-K5760

SCREW

30

20E-60-K4980

BUSHING

31

20E-60-K5240

BOLT

32

20E-60-K5590

WASHER

33

20E-60-K5730

SEAL

34

20E-60-K6310

BUSHING

35

20E-60-K5110

CAP

36

20E-60-K5120

SPRING

37

20E-60-K5150

SPRING

38

20E-60-K5320

SPRING

39

20E-60-K5920

WASHER

40

20E-60-K4990

CAP

41

20E-60-K5610

O-RING
