Запчасти Komatsu PW170ES-6K-KA ОБОГРЕВАТЕЛЬ. КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-977-K392

HEATER ASS'Y

|1

20Y-977-K391

HEATER ASS'Y

2

01010-81025

BOLT

2A

20Y-970-K760

SPACER

3

01643-31032

WASHER

4

20Y-977-K230

SEAL

5

20Y-977-K240

FILTER ASS'Y

6

20Y-977-K260

ELEMENT

7

20Y-977-K280

NUT

8

01580-10605

NUT

9

01643-30623

WASHER

10

20Y-977-K380

DUCT

11

20Y-977-K310

CABLE

12

20Y-977-K321

CABLE

13

20Y-977-K340

CONTROLLER ASS'Y

|13

20Y-977-K360

KNOB

14

20Y-977-K370

SWITCH

15

01023-10510

SCREW

16

20E-06-K1870

RESISTOR

17

08036-10610

CLIP

18

206-979-K320

CLIP

18A

20Y-977-K460

CLIP

18B

20Y-977-K480

CLIP

19

09483-00527

HOSE

20

203-62-58210

MARK¤ T1

21

09483-00522

HOSE

22

203-62-58220

MARK¤ T2

23

08036-02514

CLIP

24

01010-81225

BOLT

|24

01010-51225

BOLT

25

01643-31232

WASHER

26

421-07-11550

CLIP

27

01010-81225

BOLT

|27

01010-51225

BOLT

28

01643-31232

WASHER

29

421-07-11550

CLIP

30

01010-81225

BOLT

|30

01010-51225

BOLT

31

01643-31232

WASHER

32

08036-02514

CLIP

33

01010-81025

BOLT

|33

01010-51025

BOLT

34

01643-31032

WASHER

35

08034-00536

BAND

36

07281-00259

CLAMP

37

20Y-977-K490

ELBOW

38

203-62-41150

COVER

39

08034-00823

BAND

40

08034-00536

BAND
