Запчасти Komatsu PW170-5K МАРКИРОВКА (ПОРТУГАЛ.) МАРКИРОВКА¤ ИНСТРУМЕНТ И РЕМКОМПЛЕКТЫ

1

203-00-51170

SEAT,NONSKID

2

205-54-76511

SEAT,NONSKID

3

20E-00-K1250

PLATE,FUEL

4

154-54-23260

SEAT,NONSKID

5

205-54-76511

SEAT,NONSKID

6

20E-00-K1270

PLATE,HYDRAULIC TANK CAP

7

20E-00-K1190

PLATE¤ CAUTION,HYDRAULIC TANK

8

21T-54-11620

SEAT,NONSKID

9

20E-00-K1310

PLATE¤ CAUTION

10

09960-01001

PLATE¤ MARK,HANDLING

11

203-00-51170

SEAT,NONSKID

12

20E-00-K1190

PLATE¤ CAUTION,RADIATOR CAP

13

20Y-00-K1580

SEAT,NONSKID

14

21T-54-11620

SEAT,NONSKID

15

20G-00-K1510

PLATE,MAXIMUM SPEED

16

203-00-K1190

PLATE¤ MARK,LINE

17

203-00-31120

PLATE¤ INSTRUCTION,HYDRAULIC OIL LEVEL

18

09690-C0315

PLATE¤ MARK,KOMATSU

19

20G-46-K1680

REFLECTOR,REFLEX

|19

01220-30512

SCREW

20

20G-00-K1342

PLATE¤ MARK,PW170

21

09960-02001

PLATE¤ MARK,HANDLING

22

20G-00-K2210

CHART¤ OIL

23

20G-46-K1680

REFLECTOR,REFLEX

|23

01220-30512

SCREW

24

20G-00-K1170

PLATE¤ CAUTION,L.H. BOOM

|24

20G-00-K1160

PLATE¤ CAUTION,R.H. BOOM

25

09690-B0630

PLATE¤ MARK,KOMATSU

26

20E-00-K1140

PLATE¤ CAUTION,SWING AREA

27

09960-01001

PLATE¤ MARK,HANDLING

28

20Y-00-K1750

PLATE¤ MARK,PEMC

29

203-00-K1180

PLATE¤ MARK,LINE

30

20G-00-K1630

PLATE,MAXIMUM SPEED

31

20G-46-K1680

REFLECTOR,REFLEX

|31

01220-30512

SCREW

32

09690-B0315

PLATE¤ MARK,KOMATSU

33

09960-02001

PLATE¤ MARK,HANDLING

34

20Y-00-K1930

PLATE¤ MARK,LINE

35

20G-00-K1342

PLATE¤ MARK,PW170

36

20G-46-K1680

REFLECTOR,REFLEX

|36

01220-30512

SCREW

37

20G-00-K1630

PLATE,MAXIMUM SPEED

38

20Y-00-K1531

PLATE¤ CAUTION,KEEP OUT OF TURNING AREA

39

20G-00-K1571

PLATE¤ MARK,KOMATSU

40

20G-00-K1520

PLATE¤ CAUTION,L.H.

41

20G-00-K1530

PLATE¤ CAUTION,R.H.

42

20G-00-K1132

DECAL,MONITOR PANEL

43

203-00-56550

PLATE,TRAVEL SPEED HI-LO LESS

44

20Y-00-K1132

PLATE¤ OPERATING,SWING PARKING BRAKE

45

20G-00-K1411

PLATE¤ OPERATING,PARKING BRAKE

46

20Y-00-K1140

PLATE¤ OPERATING,FUEL CONTROL

47

20G-00-K1582

PLATE¤ OPERATING,TRANSMISSION HI-LO

48

20G-00-K1380

PLATE¤ OPERATING,OUTRIGGER (WITH OUTRIGGER)

|48

20G-00-K1390

PLATE¤ OPERATING,DOZER (OUTRIGGER LESS)

49

20G-00-K1461

PLATE¤ OPERATING,SWING LOCK

50

20E-00-K1280

PLATE¤ OPERATING,T.V.C. SWING AND PROLIX

51

09685-00002

PLATE¤ OPERATING,LOCK LEVER

52

20E-00-K1320

PLATE¤ CAUTION,STEERING CONTROL

53

20G-00-K1773

PLATE¤ NAME,(LIMITED SUPPLY)

|53

20G-00-K1772

PLATE¤ NAME,(LIMITED SUPPLY)

|53

20G-00-K1771

PLATE¤ NAME,(LIMITED SUPPLY)

|53

205-00-72430

RIVET

54

20E-00-K1210

PLATE¤ CAUTION,ACCUMULATOR

55

20E-00-K1120

PLATE¤ INSTRUCTION,AIR TANK

56

20G-00-K1451

PLATE¤ OPERATING,SERVICE BRAKE

57

20G-00-K1620

PLATE¤ OPERATING,BUCKET/CAB CONTACT

58

20G-00-K2190

PLATE¤ CAUTION,WARNING

59

20E-00-K1170

PLATE¤ CAUTION,WARNING

60

20E-00-K1230

PLATE¤ CAUTION,AUTO LOCK

61

09696-10078

PLATE,SOUND PRESSURE LEVEL

62

09696-00108

PLATE,SOUND POWER LEVEL

63

20G-00-K1470

PLATE,BRAKE PEDAL

64

20G-00-K1480

PLATE,TRAVEL PEDAL

65

20E-00-K1120

PLATE¤ INSTRUCTION,AIR CLEANER

66

205-00-K1230

PLATE,ENGINE (NOT SHOWN)

67

20Y-00-K2380

PLATE¤ MARK,RECOMMENDED LUBRICANT
