Запчасти Komatsu PW170-5K МАРКИРОВКА (ПОРТУГАЛ.) (СПЕЦ-Я TBG) МАРКИРОВКА¤ ИНСТРУМЕНТ И РЕМКОМПЛЕКТЫ

1

203-00-51170

SEAT,NONSKID

2

205-54-76511

SEAT,NONSKID

3

20E-00-K1250

PLATE,FUEL

4

154-54-23260

SEAT,NONSKID

5

205-54-76511

SEAT,NONSKID

6

20E-00-K1270

PLATE,HYDRAULIC TANK CAP

7

20E-00-K1190

PLATE¤ CAUTION,HYDRAULIC TANK

8

21T-54-11620

SEAT,NONSKID

9

20E-00-K1310

PLATE¤ CAUTION

10

09960-01001

PLATE¤ MARK,HANDLING

11

203-00-51170

SEAT,NONSKID

12

20E-00-K1190

PLATE¤ CAUTION,RADIATOR CAP

13

20Y-00-K1580

SEAT,NONSKID

14

09685-00003

PLATE¤ OPERATING,LOCK BOOM

15

21T-54-11620

SEAT,NONSKID

16

20G-00-K1510

PLATE,MAXIMUM SPEED

17

203-00-K1190

PLATE¤ MARK,LINE

18

203-00-31120

PLATE¤ INSTRUCTION,HYDRAULIC OIL LEVEL

19

09690-C0315

PLATE¤ MARK,KOMATSU

20

20G-46-K1680

REFLECTOR,REFLEX

|20

01220-30512

SCREW

21

20G-00-K1342

PLATE¤ MARK,PW170

22

09960-02001

PLATE¤ MARK,HANDLING

23

20G-00-K2210

CHART¤ OIL

24

20G-46-K1680

REFLECTOR,REFLEX

|24

01220-30512

SCREW

25

20G-00-K1170

PLATE¤ CAUTION,L.H. BOOM

|25

20G-00-K1160

PLATE¤ CAUTION,R.H. BOOM

26

09690-B0630

PLATE¤ MARK,KOMATSU

27

20E-00-K1140

PLATE¤ CAUTION,SWING AREA

28

09960-01001

PLATE¤ MARK,HANDLING

29

20Y-00-K1750

PLATE¤ MARK,PEMC

30

203-00-K1180

PLATE¤ MARK,LINE

31

20G-00-K1510

PLATE,MAXIMUM SPEED

32

20G-46-K1680

REFLECTOR,REFLEX

|32

01220-30512

SCREW

33

09690-B0315

PLATE¤ MARK,KOMATSU

34

09960-02001

PLATE¤ MARK,HANDLING

35

20Y-00-K1930

PLATE¤ MARK,LINE

36

20G-00-K1342

PLATE¤ MARK,PW170

37

20G-46-K1680

REFLECTOR,REFLEX

|37

01220-30512

SCREW

38

20G-00-K1510

PLATE,MAXIMUM SPEED

39

20Y-00-K1531

PLATE¤ CAUTION,KEEP OUT OF TURNING AREA

40

20G-00-K1520

PLATE¤ CAUTION,L.H.

41

20G-00-K1571

PLATE¤ MARK,KOMATSU

42

20G-00-K1530

PLATE¤ CAUTION,R.H.

43

20G-00-K1132

DECAL,MONITOR PANEL

44

203-00-56550

PLATE,TRAVEL SPEED HI-LO LESS

45

20Y-00-K1132

PLATE¤ OPERATING,SWING PARKING BRAKE

46

20G-00-K1411

PLATE¤ OPERATING,PARKING BRAKE

47

20Y-00-K1140

PLATE¤ OPERATING,FUEL CONTROL

48

20G-00-K1582

PLATE¤ OPERATING,TRANSMISSION HI-LO

49

20G-00-K1380

PLATE¤ OPERATING,OUTRIGGER (WITH OUTRIGGER)

|49

20G-00-K1390

PLATE¤ OPERATING,DOZER (OUTRIGGER LESS)

50

20G-00-K1461

PLATE¤ OPERATING,SWING LOCK

51

20E-00-K1280

PLATE¤ OPERATING,T.V.C. SWING AND PROLIX

52

09685-00002

PLATE¤ OPERATING,LOCK LEVER

53

20E-00-K1320

PLATE¤ CAUTION,STEERING CONTROL

54

20Y-00-K1790

PLATE,LOCK LEVER

55

20G-00-K1773

PLATE¤ NAME,(LIMITED SUPPLY)

|55

20G-00-K1772

PLATE¤ NAME,(LIMITED SUPPLY)

|55

20G-00-K1771

PLATE¤ NAME,(LIMITED SUPPLY)

|55

205-00-72430

RIVET

56

20E-00-K1210

PLATE¤ CAUTION,ACCUMULATOR

57

20E-00-K1120

PLATE¤ INSTRUCTION,AIR TANK

58

20G-00-K1451

PLATE¤ OPERATING,SERVICE BRAKE

59

20G-00-K1620

PLATE¤ OPERATING,BUCKET/CAB CONTACT

60

20G-00-K2190

PLATE¤ CAUTION,WARNING

61

20E-00-K1170

PLATE¤ CAUTION,WARNING

62

20E-00-K1230

PLATE¤ CAUTION,AUTO LOCK

63

09696-10078

PLATE,SOUND PRESSURE LEVEL

64

09696-00108

PLATE,SOUND POWER LEVEL

65

20G-00-K1470

PLATE,BRAKE PEDAL

66

20G-00-K1480

PLATE,TRAVEL PEDAL

67

20E-00-K1120

PLATE¤ INSTRUCTION,AIR CLEANER

68

205-00-K1230

PLATE,ENGINE (NOT SHOWN)

69

20Y-00-K2380

PLATE¤ MARK,RECOMMENDED LUBRICANT
