Запчасти Komatsu PW160-8 TWO-ЧАСТИ СТРЕЛА, -НАВЕСН. ОБОРУД, 1-Я СТРЕЛА, ГИДРОЛИНИЯ TWO-ЧАСТИ СТРЕЛА, -НАВЕСН. ОБОРУД

1

20G-62-41510

Tube

2

20G-62-41520

Tube

3

20G-62-41530

Tube

4

20G-62-41540

Tube

5

02896-61015

O-Ring

6

21K-62-34310

Flange

7

07000-13030

O-Ring

8

07002-62434

O-Ring

9

07372-31035

Bolt

10

01643-51032

Washer

11

20G-60-K1740

Valve

12

02782-10524

Elbow

13

07002-62434

O-Ring

14

20G-62-41570

Tube

15

20G-62-45110

Tube

16

07000-13032

O-Ring

17

02777-00518

Hose

18

02777-00509

Hose

19

07099-01009

Hose

20

07371-31049

Flange, Split

21

07372-21035

Bolt

22

01643-51032

Washer

23

20G-62-41590

Tube

24

20G-62-41610

Tube

25

02777-00510

Hose

26

20G-70-34480

Bracket

27

203-62-58810

Cushion

28

20G-70-34210

Plate

29

01010-81070

Bolt

30

01643-31032

Washer

31

01010-81025

Bolt

32

01643-31032

Washer

33

20G-70-34220

Plate

34

20G-70-34260

Bracket

35

20G-70-K2330

Cushion

36

20G-70-34230

Seat

37

20G-70-34240

Plate

38

01011-81015

Bolt

39

01643-31032

Washer

40

20G-70-34461

Bracket

41

01016-51035

Bolt

42

01643-31032

Washer

43

01597-01009

Nut

44

07283-33450

Clip, Pipe

45

07283-53444

Seat, Pipe
